USER MANUAL
Power requirement
External power supply
Max. power consumption
3.0
PACKAGE CONTENT
Before attempting to use this unit, please check the packaging and make sure the following items are
contained in the shipping carton:
1)
1x Main unit No. 1 Sender
2)
1x Main unit No. 2 Receiver
3)
2x 5V DC Power Supply
4)
1x User manual
4.0
PANEL DESCRIPTION
Sender
Empfänger
06
1)
DC/5V
Power supply for the sender
2)
HDMI In
Connect HDMI source to this port
3)
TCP/IP
Connect the sender to the receiver or ethernet router or hub by using a Cat5e/6 cable
4)
DC/5V
Power supply for the receiver
5)
HDMI Out
Connect HDMI sink device to this port
HDMI over TCP/IP
Extender Set
Sender
HDMI over TCP/IP
Extender Set
Receiver
2x DC 5V/2A
Sender 2,5 W
Receiver 2,5 W
