CAUTION: Wear cotton gloves or other covering while servicing lamp. Touching lamp glass with
bare fingers will leave oil and may cause the lamp to explode or reduce lamp life. If required, use
alcohol and cotton cloth to thoroughly clean glass portion of lamp.
Step 4. Remove lamp by pulling straight out of socket.
Step 5. Install new lamp by pressing into socket. Ensure lamp is fully seated in socket and parallel
to guide rods. (Lamp can be damaged when inserted through reflector if not parallel to
guide rods.)
Step 6. Align guide rods in guide holes and slide backcap into head assembly. Re-tighten captive
knob.
Step 7. If required, reset lamp hour counter as follows. (Refer to
for more information.)
a. Power up luminaire.
b. At Menu Display, press [Menu].
c. Press [Up] / [Down] arrows until Config (Configuration) appears. Press [Enter].
d. Press [Up] / [Down] arrows until LAMP appears. Press [Enter].
e. Press [Up] / [Down] arrows to access ResetHrs (Reset Lamp Hours). Press [Enter] to
Step 8. Align lamp. Refer to
02.9 676.00 19 A
reset lamp hour counter.
"Align Lamp for Flat Field" on page
05-January-2004
T
ROUBLESHOOTING AND
"Menu System" chapter on page 49
19.
A
M
AINTENANCE
67
