Further Support; Technical Data - Hirschmann Rps60 Beschreibung Und Betriebsanleitung

– all output lines are designed for the out-
put current of the power module and
connected with the correct polarity.
– adequate cooling is guaranteed.
2.4 REMOVAL – TAKING THE RPS 60
OFF THE MOUNTING RAIL
To unlock, press the button on the top the
RPS60 (see Fig. 6).
Take the device off the rail.
Fig. 6: Button to unlock the RPS60

3. Further support

For technical questions, please contact any
Hirschmann dealer in your area or Hirsch-
mann directly. You will find our list of our
dealers

4. Technical data

Allgemeine Daten
General data
Input voltage
Rated value
AC continuous running (full load)
DC continuous running (full load)
Mains frequency
Input current (at 264 VAC and cold start)
Rated value
Activation current
Buffer time
Overcurrent protection in the input
Output
Rated voltage
Tolerance
Residual ripple
Rated current
Reserve capacity/overload behavior
Output frequency
Permissible load
(at -10°C...+60°C and
Convection cooling)
Efficiency
Losses
Connectable in parallel
Connection leads (input and output)
Fig. 5: Mounting the RPS60
– in the Internet(http://www.hirschmann.de).
Our Hotline is also available.
Tel. +49 7127-14-1538
Fax +49 7127-14-1542
The primary area of application of the RPS60 rail - power modules is primarily switched-
mode serial power modules for the modular installation, designed for professional
applications. They may not be accessible when in operation. Installation and starting
operation may only be carried out by qualified personnel.
Switch setting to 230V
AC 230 V
176 - 264 VAC
160 - 375 VDC
47 - 63 Hz
Switch setting to 230V
< 0.7 A
< 25 A
> 20 ms (196 VAC)
Internal fuse
short-circuit, idle running and overload proof
24 VDC +5% -1%
2% above everything
< 25 mV incl. Spikes
ss
2.5 A (60 W)
Overload Design, see Chapter. 1.1 "General functions and features"
0 Hz
AC/DC Switch
in
176 - 264 VAC 230V
95 - 176 VAC 230 V
85 - 132 VAC 115 V
160 - 375 VDC 230 V
120 - 160 VDC 230 V
80 - 120 VDC 230 V
(To start with the DC input > 95 VDC is necessary)
type 87.5 %
type 8.6 W
yes
flexible cable:
fixed/rigid cable:
Switch setting to 115V
AC 115/230 V
85 - 132 VAC
not permissible!
47 - 63 Hz
Switch setting to
< 1.3 A
< 25 A
I with 24 V
out
2.5 A
1.5 A
2.5 A
2.5 A
2.0 A
1.5 A
2
1.5...4 mm (on the output also 0.5 mm
2
1.5...6 mm (at the output also 0.5 mm
2
)
2
)
7
