LED fl oodlight with motion detector
LED fl oodlight
By purchasing this item, you have chosen a high-quality GEV
product. Please read these operating instructions carefully to
ensure correct operation. Keep these instructions in a safe
place so that you can refer back to them if necessary.
Operation
LED fl oodlight with motion detector
The LED fl oodlight with motion detector functions using passive
infrared technology. If the motion detector's PIR sensor detects
a moving heat source in its fi eld of detection, it switches on
automatically. Static heat sources do not activate the motion
detector. The adjustable twilight switch can be set to ensure that
the motion detector will operate either during the day and night
or only when it is dark. When movement is detected, the motion
detector switches on the LED and then switches it off again
between approx. 3 seconds and approx. 4 minutes after the last
movement is detected, depending on the setting.
Safety instructions
This device must be installed by a technician, in
accordance with the applicable regulations. The electrical
power supply and the circuit protection must be switched
off during the entire installation process. Please check
that the connection cable is disconnected!
Under no circumstances does the warranty cover damage resulting
from failure to observe these instructions. Nor do we accept liability
for any indirect damage.
Similarly, we can accept no liability for any material damage or
bodily injury caused by mishandling or failure to observe the safety
instructions. No warranty claim may be made in these cases.
In addition, for safety and compliance reasons, you are not
authorised to dismantle or alter the device in any way.
Mounting position
LED fl oodlight with motion detector
Motion detection is maximised when you move at an angle to the
motion detector. Therefore, the motion detector should always be
installed in a position that ensures that you do not move directly
towards the device.
Installation
Install the light as shown in Figs. B to D. Connect the mains
connection cable as shown in the wiring diagram (Fig. D).
Settings
LED fl oodlight with motion detector (Fig. E)
SENS sets the range of detection
TIME sets the ON period to between approx. 3 s and 4 min
LUX adjusts the twilight switch to between approx. 4 and
1,000 lux
The motion detector can be adjusted horizontally (Fig. F) and
vertically (Fig. G). To do this, simply undo the screws (G1), adjust
the detector (G2) and then retighten the screws (G3).
Adjust the LED fl oodlight to the required position and then tighten
the nuts (Fig. B1).
Recycling instructions
This device may not be disposed of with unsorted household
waste. Owners of old devices are required by law to dispose
of this device correctly. Contact your town council for further
information.
4
Technical data
Operating voltage
Light colour
LED angle of radiation
Protection class
Recommended installation height
Order Number 015005
LED/LEDs light power approx. 1 x 10 W
Luminous fl ux approx. 720 lm
Protection type
Approx. dimensions
115 x 87 x 90
width x height x depth in mm
Order Number 015401
Field of detection
Range
Time setting
Twilight switch
LED/LEDs light power approx. 1 x 10 W
Luminous fl ux approx. 720 lm
Protection type
Approx. dimensions 115 x 155 x
width x height x depth in mm 105
Gutkes GmbH
Rehkamp 13 Fax: +49 (0)511/95 85 805
30853 Langenhagen www.gev.de
Germany service@gev.de
230 V ~, 50 Hz
6,500 K
approx. 120°
I
2.5 m
015012 015029
1 x 20 W 1 x 30 W
1,440 lm 2,160 lm
IP65
182 x 143 x 123 225 x 185 x 128 290 x 240 x 140
015418 015425 015609
180 °
approx. 13 m, depending on the installation height
approx. 3 seconds to 4 minutes
after the last movement is detected (infi nitely variable)
approx. 4 - 1,000 lux, infi nitely variable
1 x 20 W 1 x 30 W 60 x 0.065 W
1,440 lm 2,160 lm 300 lm
IP44
180 x 210 x 225 x 235 x 190 x 250 x
115 128 100
μ = contact gap < 1.2 mm
Technical and design features may be subject to change without notice.
5
015036
1 x 50 W
3,600 lm
015616
130 x 0.065 W
650 lm
190 x 250 x
100
