Machine buttons

3
20 21
1. Up
2. OK
3. Home
4. Left
5. Down
6. Indicator
7. Power Switch
8. Menu

Keys Introduction

2 1 10 9
K K
4 5 6 7
22
9. Return
10. Right
11. Keystone Wheel
12. Focus Wheel
13. TF Card Slot
14. USB Input
15. HDMI Interface
16. AV Input
3
12
11
19
8
23
17. Audio Output
18. VGA Input
19. Power Input
20. Lens
21. Height Adjustment Nut
22. IR Lamp
23. Speaker
16
TF
AV
HD
USB
13 14
15 18 17
