Functional Elements - Dreve EyeVolution Gebrauchsinformation

EyeVolution

6. Functional elements

8
6
5
No. Description
1 Power supply connector socket
2 Main switch
3 Display foil
4 Time programme push-button
5 Rotary plate function push-button
6 Function display
7 Rotary plate
8 Reflective foil
9 LED circuit board
10 Glare protection cap
11 Cover handle
12 Device cover
13 Inspection window
22
®
13
12
11
10
9
7
3
4
2
1
