FHF PH1 Bedienungsanleitung Seite 2

Pneumatikhorn

Werbung

bmessungen / Dimensions
105 mm
(4.1")
nschluss / Connection
nschlussgewinde innen 1/2"
Connection thread inside 1/2"
Luftfilter
ir filter
W RNUNG:
Dauerhafte Beschallung kann zu Gehörschäden
fu ̈ hren. Um Gehörschäden zu vermeiden muss die
Installation des Pneumatikhornes PH1 in einem sicheren
Abstand zu Arbeitsplätzen erfolgen.
Änderungen und Irrtum vorbehalten
375 mm
(14.8")
Rohr- ußendurchmesser 8 mm / 0,32"
Pipe outside diameter 8 mm / 0.32"
FHF Funke + Huster Fernsig GmbH
Gewerbeallee 15-19 · D-45478 Mülheim an der Ruhr
Phone +49 / 208 / 82 68-0 · Fax +49 / 208 / 82 68-286
http://www.fhf.de · e-mail: info@fhf.de
35 mm
(1.4")
60 mm
(2.4")
Rohranschluss – Schlüsselweite 14
Pipe connection – wrench size 14
TTENTION:
Sonication can lead to permanent hearing damage. To
avoid hearing damage, the installation of the pneumatic
horn PH1 done at a safe distance to jobs.
Diameter of holes:
Ø 7 mm
40 mm
(1.6")
Subject to alterations or errors
