Note:
1. The IP address of print server must be within the same subnet
as your network adapter.
2. After you save the new IP address, the print server will auto-
matic reboot once to make ready for the new IP address. It may
take a couple of seconds.
8. On the Select A Printer screen, select an already configured
printer from the list, click Next and then Finish to complete the
installation.
or
Select Add New Printer if the print server is connected to a
printer that hasn't been installed before and does not appear in
the list. (Figure 4)
9. Click Add New Printer to launch Windows Add Printer Wizard.
(Figure 4)
10. Click Next and select Local Printer, make sure the Automati-
cally detect and install my Plug and Play printer check box is
NOT checked. Then click Next. (Figure 5)
11. Make sure the Use the following port radio-button is clicked
and select LPT1: (Recommended Printer Port) from the pull-
down list. Then click Next. (Figure 6)
Select Manufacturer and Printer from the lists of printer's driver.
12.
Then click Next. (Figure 7)
If you already have the printer's driver installed, you will be
13.
asked whether to keep it or to replace it. Click Next. Supply a
name for the printer and choose whether you want to make it
your default printer. Then click Next. (Figure 8)
14. Then, choose whether you want to share the printer with other
network users, print a test page (please select No.), etc. Select
the appropriate radio-button and click Next and Finish (Figure
8).
15. In the setup wizard, finish the installation by highlighting the in-
stalled printer in the Select a Printer list and click Next ->
Finish. (Figure 8)
