Proel XE51CT Benutzer- Und Installationsanleitung Seite 7

XE51CT
XE65CT
ø165 mm XE51CT
ø179 mm XE65CT
1
XE65CT
XE51CT
BLACK - C BLACK - C
3
BLUE - 2.5W RED - 2.5W
BROWN - 5W YELLOW - 5W
WHITE - 10 W WHITE - 10 W
BROWN - 20 W
4
5
6
2
BLACK
-
+
RED
100V speaker line
(from amplifier)
