Avision Network Box Schnelleinrichtungsanleitung Seite 2

Ports and LED
"24VDC OUT" Port: Used to connect the power cable (included) to the scanner.
USB Port: Used to connect the USB cable (included) to the scanner.
Power LED: Turns green when the Network Box is powered on.
Status LED: The color of the LED indicates the connection type and status.
LED Color
Orange
Green
Red
Wi-Fi/LAN LED: The Wi-Fi feature is available only for the Wi-Fi version.
"LAN" Port: Used to connect the LAN cable to the Network Box for wired network connection.
"5VDC 1.5A" Port: For scanner without a 24VDC power jack, use this port to connect the box
to a USB power adapter via a Micro USB cable.
"24VDC IN" Port: Used to connect the power adapter that comes with the scanner to the
Network Box.
"WPS" : Available only for the Wi-Fi version.
"Reset" Button: Restore to factory default settings. To reset the Network Box, use a pen to press and
hold this button for about 5 seconds. Release the button and the orange LED turns off. Wait for at least
60 seconds until the orange LED starts blinking (without connecting the ethernet cable) or turns solidly
on (with ethernet cable connecting to Network Box).
2
Status Description
Wired LAN mode with scanner connecting to the Network Box
Solid
Wired LAN mode with scanner disconnecting to the Network Box.
Solid
Firmware updating
Solid
