5. CONNECTIONS

AUDIO
MIC2 L
AGND
MIC2 R
AVCC
FRO-R
MIC2_JD
F_IO_SEN
LINE2_JD
FRO-L
10
PANEL
Power LED +
Reset SW
Power LED -
Power SW H.D.D LED
USB 3.0
IntA P2_D+
ID
IntA P2_D-
IntA P1_D+
GND
IntA P1_D-
IntA P2_SSTX+
GND
IntA P2_SSTX-
IntA P1_SSTX+
GND
IntA P1_SSTX-
IntA P2_SSRX+
GND
IntA P1_SSRX+ IntA P2_SSRX-
IntA P1_SSRX-
Vbus
Vbus No Pin
