Custom Mode; Package Content - Genesys Rhod 600 RGB Kurzanleitung

features
anti-ghosting function for 19 keys
6 zone RGB backlight with PRISMO e ect
gaming software with pro le and macro editor
programmable keys
multimedia keys
Instalation
Connect your device to the USB port of your computer, it is
necessary to wait about 15 seconds for the rst connection
until the drivers are fully installed. The keyboard includes
software that allows you to set up advanced features, if you
want to use these features, you need to download and install
the software from our website www.genesis-zone.com.
Open the installation folder and then double-click the
setup.exe le. Follow the installation instructions. After a
successful installation, the software icon appears on the
main bottom panel. Double-clicking the icon opens the
settings interface.
NOTE: 6 macros can be assigned to each of 3 pro les. The
required pro le must be selected before you start recording.

CUSTOM MODE

Custom mode allows you to set the individual
illumination of each zone
1. Hold FN button and double press button 7 to enter
into "Custom Mode"
2. Press the FN + arrow Up/Down to change color
3. Press the FN + arrow Right/Left to move between
6 zones
4. Hold FN button and double press button 7 to save
settings
MACRO RECORDING
To start the recording, press the key "MR" (the LED indicator
will start ashing), then select one of the G1-G6 keys (the
LED will ashing quicker), then press the key combination
which you want to assign. To stop the recording and save the
macro, press "MR" again (the LED indicator will go o ).

PACKAGE CONTENT

Rhod 600 RGB gaming keyboard
Quick installation guide
SAFeTY information
Use as directed.
Non-authorized repairs or taking the device to pieces make the
warranty void and may cause the product damage.
Avoid to hit or friction with a hard object, otherwise it will lead to
grind surface or other hardware damage.
Do not use the product in low and high temperatures, in strong
magnetic elds and in the damp or dusty atmosphere.
Do not drop, knock, or shake the device. Rough handling can break it.
Slots and openings in the case are provided for ventilation and should
not be obscure. Blocking the vents can cause overheating of the
device.
Arrow function change
Press Fn + W keys to swap arrow
function with W, A, S, D keys function.
FN
+
W
BACKLIGHT
BRIGHTNESS
To change the backlight brightness level press
keys Fn + Pg Up/Pg Dn
BACKLIGHT
MODE CHANGE
Press the keys Fn+1-9 to change between
9 backlight modes
1.
FN
+
7
2x
requirements
PC or PC compatible device with a USB port
Windows® XP/Vista/7/8/10
W
A S D
2.
FN+
3.
FN+
warranty
2 years limited manufacturer warranty
general
The safe product, conforming to the EU requirements.
The product is made in accordance with RoHS European
standard.
The WEEE symbol (the crossed-out wheeled bin) using
indicates that this product in not home waste. Appropriate
waste management aids in avoiding consequences which
are harmful for people and environment and result from
dangerous materials used in the device, as well as improper
storage and processing. Segregated household waste
collection aids recycle materials and components of which
the device was made. In order to get detailed information
about recycling this product please contact your retailer or a
local authority.
EN
PL
CZ
SK
DE
RO
RU
PG
UP
FN+
PG
DN
4.
FN
+
7
2x
