Please see Fig. B (Page 1) that shows how to install the CXM remote display on a
standard 35mm DIN rail.
[ Wall Mounting ]
Please see Fig. C (Page 2) that shows how to install the CXM remote display on the
wall.

Display Function

[ Current Value ]
Push the right button to toggle the parameters of your PV system today.
The parameters displayed in the LCD will toggle in this order :
SOC - V (Battery Voltage) - I (Panel Current) - I (Load Current) - Ah
(Panel
bat in out in
Amperehours) - Ah (Load Amperehours) - Total Ah
(Total Panel Amperehours since
out in
PV system build up) - SOC - V
(Battery Voltage) - ...
bat
Please see Fig. D (Page 3) for reference.
[ History Data]
Step 1: First push the left button to toggle the day (Day 1 means yesterday).
The days displayed in the LCD will toggle in this order :
Day 1 - Day 2 - Day 3 - Day 4 - Day 5 - Day 6 - Day 7 - Today - Day 1 - Day 2 - ...
Please see Fig. E (Page 4) for reference.
