8. ANTENNA CONNECTION

The IZAR RDC STANDARD can also be equipped
with optional external antenna connections for ISM
(868 MHz or 434 MHz) and GSM/GPRS. Make sure the
antennas connected are for the appropriate frequencies
(see labelling of connections).
The external antennas are only for use indoors. The
maximum permissible length of cable for the external
GSM / GPRS antenna is <1 m. No liability is accepted for
damage due to external antennas (e.g. lightning strike,
condensation).
Use only antennas specified by DIEHL Metering.

9. DISPLAY ELEMENTS

The operating status is indicated by 2 integrated LEDs
on the front.
10. PROGRAMMING
Programming is performed exclusively via the
IZAR@SET software.
