Stückliste Part List - Atx Rhe Ii Aufbauanleitung
Reverse hyper extension
Inhaltsverzeichnis
Beachte: Einige der gelisteten Teile sind möglicherweise bereits vormontiert!
Vormontierte Bauteile / Schrauben kontrollieren und gegebenenfalls nachjustieren / festziehen!
Note: Some of this parts may come pre-assembled!
Check all the pre-assembled parts and screws and readjust or tighten them if necessary.
List No.:
Quantity:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
ATX-RHE-II Reverse Hyper Extension
Item-No.:
2
ATX-RHE-B01000
2
ATX-RHE-B02000
1
ATX-RHE-B03000
1
ATX-RHE-B04000
1
ATX-RHE-P05001-L
1
ATX-RHE-P05001-R
2
ATX-RHE-P06001
1
ATX-RHE-B07000
1
ATX-RHE-B08000-L
1
ATX-RHE-B08000-R
1
ATX-RHE-B09000
1
ATX-RHE-P10001
2
ATX-RHE-B11000
1
ATX-RHE-B12000
1
ATX-RHE-PAD-02
2
UCP-206
2
6004-2RS
4
ATX-RS-80
2
ATX-WPP-BUM-50
-
1
ATX-SPRING-CLIP
8
SB-70-50-200
2
IFS-DPIN-12
4
ATX-METAL-5x10
2
ATX-RHE-P06001-PVC
2
SRL48-R9005
2
TubePlug-80
2
VL8060-R9005
2
S-RING-W20
2
LKS-M6x14
4
LKS-M8x20
2
LKS-M12x25
2
ZKS-M8x20
2
SKS-M10x30
2
SKS-M10x100
2
SKS-M12x95
27
SKS-M14x110
4
S-MUTTER-M8
2
S-MUTTER-M12
27
S-MUTTER-M14-DIN982
4
S-MUTTER-M16
4
SKS-M16x55
4
U-Scheibe-3xd-10
30
U-Scheibe-3xd-14
6
U-Scheibe-B8
4
U-Scheibe-B12
24
U-Scheibe-B14
8
U-Scheibe-B16
Description
ATX RHE Upholstery Panel - PAD-02
Plummer Block UCP 206
Ball-Bearing 6004-2RS
ATX-RS-80 Rubber Boot
ATX WPP Bumper - 50 mm tube
ATX Spring Clip
Slide Bar 70-50-200 - PA66
IFS Detent Pin 12 mm
ATX Aluminium Label 50 x 100 mm
PVC Lamination - white
Tube Plug round 48 mm
Tube Plug 80 x 80 mm
Tube Plug 80 x 60 mm
Retaining Ring external 20 mm DIN 471
Hexagon Socket Button Head Cap Screw M6x14mm
Hexagon Socket Button Head Cap Screw M8x20mm
Hexagon Socket Button Head Cap Screw M12x25mm
Hexagon Socket Head Cap Screw M8x20mm
Hex Bolt M10x30mm
Hex Bolt M10x100mm
Hex Bolt M12x95mm
Hex Bolt M14x110mm
Auto-Lock-Nut M8
Auto-Lock-Nut M12
Auto-Lock-Nut M14 - High Design DIN 982
Auto-Lock-Nut M16
Hex Bolt M16x55mm
Washer M10 Large Diameter 3xD
Washer M14 Large Diameter 3xD
Washer M8
Washer M12
Washer M14
Washer M16
STÜCKLISTE
PART LIST
