Manual: MicroNet Slim - Network Interface
5.2 DMX Mode
Dip switch setting
switch
1
Binary DMX
1
channel offset
To get laser output, DMX channel 1 needs to have a value greater than 0 (recommended 64
to 192), and DMX channel 2 also needs to have a value greater than 0.
DMX settings
channel
range
1
0-63
64-192
193-255 Strobe with increasing speed
2
0-255
3
0-192
193-255 Automatic size change of X axis with increasing speed
4
0-192
193-255 Automatic size change of Y axis with increasing speed
5
0-192
193-255 Automatic position change of X axis with increasing speed
6
0-192
193-255 Automatic position change of Y axis with increasing speed
7
0-192
193-255 Automatic rotation with increasing speed
8
0-192
193-255 Automatic blanking with increasing speed
9
0-192
193-255 Automatic blankshift with increasing speed
10
0-15
16-31
32-47
48-63
64-79
page 7 / 20
2
3
4
5
2
4
8
16
function
Laser intensity from off to full brightness
(only if lasers support analog modulation)
Laser full brightness
select the laser frame pattern
Size of the laser projection X axis
Size of the laser projection Y axis
Position of the laser projection X axis
Position of the laser projection Y axis
Rotation of the laser projection
Blanking: selects how much of the laser pattern shall be blanked
Blankshift: selects which part of the laser projection shall be blanked (use only
in combination with channel 7 - blanking)
Show pattern in original colors
Pattern completely red
Pattern completely green
Pattern completely blue
Pattern completely yellow
6
7
8
9
32
64
128
256
10
has to be on (1) for DMX mode
