Manual: MicroNet Slim - Network Interface
Dip switch setting
switch 1
On (1) / Off (0)
The Windows computer needs to have an IP address within the same network subnet.
Example:
switch 1
On (1) / Off (0) 1
This will assign IP address 192.168.0.61 to the ILDA interface.
Assign a different IP address inside the same subnet to the Windows computer, for example
192.168.0.100 (subnet = 255.255.255.0)

6. Power Supply

6.1 Power supply via power cable
Use the power cable (included in the delivery) to connect the network interface with the power supply.
6.2 Power supply via USB connection
Important: Depending on the connected ILDA projector and DMX equipment, the network
interface might draw more than 500mA. Therefore, the board might exceed the maximum al-
lowed power of a computer USB port. It is not recommended to connect the network interface
via its USB port to a computer's USB port. An external USB power supply with >=800mA
should be used instead.
High quality USB cables should be used. Avoid long and thin cables, because this will result in
a weak power supply and degraded ILDA signal quality.
page 10 / 20
2 3 4
0000 - adr2 = 50
1000 - adr2 = 51
0200 - adr2 = 52
1100 - adr2 = 53
0010 - adr2 = 54
1010 - adr2 = 55
0110 - adr2 = 56
1110 - adr2 = 57
0001 - adr2 = 58
1001 - adr2 = 59
0101 - adr2 = 60
1101 - adr2 = 61
0011 - adr2 = 62
1011 - adr2 = 63
0111 - adr2 = 64
1111 - adr2 = 65
2 3 4
1 0 1
5 6 7
00 - adr1 = 0 1
10 - adr1 = 1
01 - adr1 = 2
11 - adr1 = 254
5 6 7
0 0 1
8 9 10
0 0 0
8 9 10
0 0 0
