1.2

How to connect the Antennae

Connect the antennae to the TNC sockets
Please note that for diversity operation both antennae have to be connected. A weighting
circuit silently switches the signal with the better S/N ratio to the output.
Important:
Avoid obstacles between antennae and transmitter; otherwise the reception could be
disturbed.
1.3 Where to place the Receiver
• Place the NE 100 S diversity receiver in the same room or area as the transmitters. Ensure
that the NE 100 S is installed as close as possible to the mixing console or amplifier so
that the display can be seen at all times.
• Do not place the NE 100 S receiver near digitally controlled equipment or other sources
of RF interference.
1.4 Connections
• Connect the Audio output to the corresponding input of the mixing console or amplifier.
Use the balanced Audio output
with a balanced input.
• Use the unbalanced Audio output
input of an amplifier.
• Make sure the Low/High switch
Switch to "High", when you connect the receiver to a mixer/amplifier. When connecting
to a guitar amplifier you should choose "High", or the volume may be too low.
Switch to "Low", when you connect the receiver to a microphone input.
Incorrect positioning of the Low/High switch
• Make sure the mains voltage shown on the power supply unit corresponds to the local
mains voltage.
• Connect the power supply unit to the receiver

Mains Connection

and
6
, when you connect the receiver to a mixer/amplifier
7
, when you connect the receiver to the "LINE"
8
9 is switched to the correct position.
can cause distortion.
9
and to AC mains power.
5

Audio Connection

and set them at an angle (60°).
11
25
