Safety regulation
•
Installation has to be conform the manual. Disregard or change of installation can
result on serious damages to people and material for which the manufacturer refu-
ses to accept any liability or obligation under warranty.
•
The windresistance of an open umbrella is limited and related of the anchoring.
Movable base are less stable than installation fi xed to the ground.
•
The ground anchorage has to be fi tted accoriding the related fi tting instruction.
Fitting has to be carried out by a specaialist with construction know-how.
•
The umbrella must not be altered or draped with a different material. Stability,
function and/or closing mechanism may deteriorate.
•
Use only original accessory and spare parts from Shademaker.
•
If the wind freshens up the sunshade must be closed.
•
Unattended sunshades must not be left open!
Installation:
•
Remove the two locking-screws from pole to detach the support tube from pole.
•
C) Place support tube onto ground socket, insert the anchorage screws (12), do
not tighten yet.
•
Place plastic-ring (2) on suppport tube.
•
Lift umbrella with two people and put carefully over support tube.
•
(D) Insert locking-screws (3) „pole/support tube" and tighten.
•
Rotate umbrella to the required position and tighten the anchorage screws (21).
•
In case umbrella does not stand vertical, loosen the anchorage screws (21) sligh-
tely and adjust with level screws (22). Retighten the anchorage screws (21) again.
Operation
•
Freed manually the ribs before opening the fi rst time.
•
Insert crank handle (5) fully into the gear.
•
Rotate handle slowly clockwise until shade is taut. Never force the ribs.
•
(E) Slider (8) will be locked at the Ant-twist PIN (9).
GB
