Specification - OK. ODL 49740U-DIB Gebrauchsanweisung

Specification

TV Broadcasting
Receiving Channels
Digital Reception
Number of Preset
Channels
Channel Indicator
RF Aerial Input
Operating Voltage
Audio
Audio Output Power
(WRMS.) (10% THD)
Power Consumption (W)
Networked Standby (W)
TV Dimensions DxLxH
(with stand) (mm)
TV Dimensions DxLxH
(without stand) (mm)
Display
Operation temperature
and operation humidity
PAL BG/I/DK
SECAM BG/DK
VHF (BAND I/III) - UHF
(BAND U) - HYPERBAND
Fully integrated digital
terrestrial-cable TV
(DVB-T-C)
(DVB-T2 compliant)
1 000
On Screen Display
75 Ohm (unbalanced)
220-240V AC, 50Hz.
German+Nicam Stereo
2 x 10
120
< 3
250 x 1112 x 709
61/93 x 1112 x 653
49"
0ºC up to 40ºC, 85%
humidity max
English - 78 -
Wireless LAN Transmitter Specifications
Frequency Ranges
2400 - 2483,5 MHz (CH1-CH13)
5150 - 5250 MHz (CH36 - CH48)
5250 - 5350 MHz (CH52 - CH64)
5470 - 5725 MHz (CH100 -
CH140)
Country Restrictions
This device is intended for home and office use in all
EU countries (and other countries following the rele-
vant EU directive) without any limitation except for the
countries mentioned below.
Country Restriction
General authorization required for outdoor
Bulgaria
use and public service
France In-door use only for 2454-2483.5 MHz
If used outside of own premises, general
Italy
authorization is required
In-door use only for 5470 MHz to 5725
Greece
MHz band
General authorization required for network
Luxembourg
and service supply(not for spectrum)
Radio transmission is prohibited for the
Norway geographical area within a radius of 20 km
from the centre of Ny-Ålesund
Russian Fed-
In-door use only
eration
The requirements for any country may change at any
time. It's recommended that user checks with local
authorities for the current status of their national reg-
ulations for both 2.4 GHz and 5 GHz wireless LAN's.
Max Output Power
< 100 mW
< 200 mW
< 200 mW
< 200 mW
