Technical Specifications - Innokin iTaste 134 Mini Bedienungsanleitung

WARNING:
Innokin provides a three month after sales service warranty to all of our authorized vendors.
Please consult Innokin official distributors for more information and terms of service.
Innokin's warranty does not apply to products purchased through third-party vendors.
Technical Specifications:
The standby current: 150uA maximum
Maximum output voltage: 6.0V (unloaded)
Maximum output current: 5.0A（Built in 7A fuse for protection and stability.）
Maximum output wattage: 12.5W (Watts mode)
Resistance of clearomizer: 1.2 ohm (minimum)
Battery: IMR high drain 18350/18500 (without protection, maximum current output is more than
5000mA.) iTaste 134 Mini cannot use 2 stacked batteries and any other types of batteries may
damage your iTaste 134 Mini.
3/EN-3
FEATURES:
Scale Display Wattage
Scale display wattage improves intuitive control and provides more accurate performance.
Variable Wattage:
The rotational wheel adjusts wattage in the following increments:
7.0 , 8.0 , 8.5 , 9.0 , 9.5 , 10.5 , 11.0 , 12.0 , 12.5 .
The red LED will blink six times and turn off if the rotational wheel is not in place.
To set your desired wattage turn the rotational wheel to the left or right until you hear a click. When
adjusting the wattage with the rotational wheel please check to ensure the wheel is set to your
desired wattage.
6/EN-4
