5301 Stevens Creek Blvd. formance of this document or of any Santa Clara, CA 95052 USA information contained herein. Should Agilent and the user have a separate written agreement with warranty WARN IN G terms covering the material in this...
3 Connect the test leads to the input terminals 4 Turn on the multimeter 5 Select a function 6 Set the range 7 Set the reading rate 8 Using the secondary display 9 Math operation 10 For more information U3402A Quick Start Guide...
The Front Panel at a Glance Primary display Secondary display Input terminals Shift Measurement Math Power Autoranging, function operation on/off and current fuse manual range keypads keypads switch and comparator operation U3402A Quick Start Guide...
AUTO Autoranging Direct current Alternating current DCAC AC + DC Polarity, digits, and decimal points for primary display ºC Celcius temperature unit. Not applicable for the U3402A. ºF Fahrenheit temperature unit. Not applicable for the U3402A. U3402A Quick Start Guide...
Seite 7
Description Voltage unit: mV, V µmA Current unit: µA, mA, A µmnF Capacitance unit: nF, µF, mF. Not applicable for the U3402A. Resistance unit: , k , M MkHz Frequency unit: Hz, kHz, MHz Secondary display Polarity, digits, and decimal points for secondary display µnmF...
The line voltage switch and fuse are set at the factory according to the country of N O TE destination. 2 Adjust the carrying handle Grasp the handle by the sides and pull outward as indicated by the red arrows below. Then, adjust the handle to the desired position. U3402A Quick Start Guide...
4 Turn on the multimeter Push to turn on the multimeter. The front- panel display illuminates while the multimeter performs its power- on self- test. The multimeter powers up in the DC voltage function with autoranging enabled. Typical display: U3402A Quick Start Guide...
A faster reading rate will result in faster but lower accuracy readings. In the dBm function, the display counts is 0.01 dBm for the slow or medium reading rate N O TE and 0.1 dBm for the fast reading rate. U3402A Quick Start Guide...
You may need to press the selected key until the multimeter responses. In dual display mode, the 9 Math operation The U3402A has five math operations — dBm, Rel (relative), MinMax, Comp (compare), and Hold. Press to select dBm measurement.
Agilent U3402A User’s and Service Guide. 10 For more information The Agilent U3402A User's and Service Guide contains more detailed information on the front panel, measurement functions, math operations, and the setup menu (allows you to customize the instrument settings). It also contains product specifications, rack mounting instructions, and replaceable parts information.
Seite 13
Multimètre double affichage 5 1/2 chiffres Agilent U3402A Guide de mise en route Agilent Technologies...
Agilent concède la les conditions indiquées n’ont pas licence commerciale habituelle sur les été parfaitement comprises et logiciels et les informations techniques suivant les directives FAR 12.211 (informations satisfaites. techniques) et 12.212 (logiciel informatique) Guide de mise en route du faradmètre U3402A...
Seite 15
4 Mise sous tension du multimètre 5 Sélection d’une fonction 6 Définition de la plage 7 Définition de la vitesse de lecture 8 Utilisation de l’affichage secondaire 9 Opération mathématique 10 Pour de plus amples informations Guide de mise en route du faradmètre U3402A...
Seite 16
Guide de mise en route du faradmètre U3402A...
La face avant Affichage principal Affichage secondaire Bornes d’entrée Touches des fonctions Touches des opérations Commutateur de de mesure mathématiques marche/arrêt et fusible Sélection automatique de Décalage plage, plage manuelle et opération du comparateur Guide de mise en route du faradmètre U3402A...
Courant alternatif + continu Polarité, chiffres et points décimaux de l’affichage principal ºC Température en degrés Celsius. Sans objet pour le U3402A. ºF Température en degrés Fahrenheit. Sans objet pour le U3402A. Guide de mise en route du faradmètre U3402A...
Seite 19
Unité de tension : mV, V µmA Unité d'intensité : µA, mA, A µmnF Unité de capacité : nF, µF, mF. Sans objet pour le U3402A. Unité de résistance : , k , M MkHz Unité de fréquence : Hz, kHz, MHz Affichage secondaire Polarité, chiffres et points décimaux de l’affichage secondaire...
2 Réglage de la poignée de transport Saisissez la poignée par les côtés et tirez vers l’extérieur tel qu’indiqué par les flèches rouges ci- après. Réglez ensuite la poignée dans la position souhaitée. Guide de mise en route du faradmètre U3402A...
Au démarrage, le multimètre active la fonction de tension continue et la sélection automatique de plage. Affichage typique: Guide de mise en route du faradmètre U3402A...
Dans la fonction dBm, la valeur est de 0,01 dBm pour les vitesses de lecture lente et R E MAR Q U E moyenne et de 0,1 dBm pour la vitesse de lecture rapide. Guide de mise en route du faradmètre U3402A...
Vous devez parfois appuyer sur la touche sélectionnée jusqu’à ce que le En mode double affichage, le multimètre réponde. 9 Opération mathématique Le U3402A propose cinq opérations mathématiques — dBm, Rel (relative), MinMax, Comp (comparaison) et Hold. Appuyez pour sélectionner la mesure de dBm. Appuyez pour sélectionner l'opération mathématique Comp.
Service Guide. 10 Pour de plus amples informations Le document Agilent U3402A User’s and Service Guide contient des informations plus détaillées sur le panneau avant, les fonctions de mesure, les opérations mathématiques et le menu de configuration (ce dernier vous permet de personnalisaer les paramètres de l'instrument).
Seite 27
1 Anschließen des Netzkabels 2 Anpassen des Tragegriffs 3 Anschließen der Testleitungen an die Eingangsanschlüsse 4 Einschalten des Multimeters 5 Auswählen einer Funktion 6 Einstellen des Bereichs 7 Einstellen der Leserate 8 Verwenden der Sekundäranzeige 9 Math. Operation 10 Weitere Informationen U3402A Schnellstarthandbuch...
Das vordere Bedienfeld auf einen Blick Primäranzeige Sekundäranzeige Eingangsanschlüsse Tastenfelder für Tasten- Ein-/Aus- Automatische Messfunktionen felder für schalter und Stromsicherung schalten Bereichswahl, math. Ope- manuelle Bereichs- rationen wahl und Vergleichs- operation U3402A Schnellstarthandbuch...
Tabelle beschrieben: Melder Beschreibung Primäranzeige Leserate: Langsam Leserate: Mittel Leserate: Schnell PEAK Spitzenmessung. Gilt nicht für U3402A. HOLD Datenhalten Math. MinMax-Operation: Auf primärer Anzeige angezeigter minimaler Wert Math. MinMax-Operation: Auf primärer Anzeige angezeigter maximaler Wert Relativer Wert...
Seite 31
Temperatur in Fahrenheit. Gilt nicht für U3402A. Spannungseinheit: mV, V µmA Stromstärkeeinheit: µA, mA, A µmnF Kapazitätseinheit: nF, µF, mF. Gilt nicht für U3402A. Widerstandseinheit: , k , M MkHz Frequenzeinheit: Hz, kHz, MHz Sekundäranzeige Polarität, Ziffern und Dezimalpunkte für Sekundäranzeige µnmF...
Leitungsspannungswahlschalter und Sicherung sind werksseitig dem Zielland gemäß HIN W EI S eingestellt. 2 Anpassen des Tragegriffs Fassen Sie den Griff an den Seiten und ziehen Sie ihn in Richtung der roten Pfeile. Bringen Sie den Griff dann in die gewünschte Position. U3402A Schnellstarthandbuch...
4 Einschalten des Multimeters Drücken Sie auf , um das Multimeter einzuschalten. Die Anzeige auf der Vorderseite ist beleuchtet, während das Multimeter seinen Einschalt- Selbsttest duchführt. Das Multimeter fährt in der DC- Spannungsfunktion mit aktivierter auto- matischer Bereichswahl hoch. Typische Anzeige: U3402A Schnellstarthandbuch...
Eine langsamere Leserate ermöglicht genauere Messungen mit höherer Rauschunterdrückung. Eine schnellere Leserate ermöglicht schnellere, jedoch ungenauere Messungen. In der dBm-Funktion beträgt die Anzeigegenauigkeit 0,01 dBm für die langsame oder HIN W EI S mittlere Leserate und 0,1 dBm für die schnelle Leserate. U3402A Schnellstarthandbuch...
(0,6 s bis 1 s). Drücken Sie die Taste, bis das Multimeter reagiert. Sekun däranzeigemodus 9 Math. Operation Das U3402A bietet fünf math. Operationen — dBm, Rel (relativ), MinMax, Comp (Vergleich) und Hold. dBm- Messung auswählen. Math. Operation Comp auswählen.
Ausführliche Verfahrensbeschreibungen für jede math. Operation finden Sie im Agilent U3402A Benutzer- und Servicehandbuch. 10 Weitere Informationen Das Agilent U3402A Benutzer- und Servicehandbuch enthält ausführ- lichere Informationen zu vorderem Bedienfeld, Messfunktionen, math. Operationen und Einrichtungsmenü (ermöglicht die Anpassung der Instru- menteneinstellungen).
(tel) 0800 047 866 (fax) 0800 286 331 Other Asia Pacific Countries: (tel) (65) 6375 8100 (fax) (65) 6755 0042 Or visit Agilent World Wide Web at: www.agilent.com/find/assist Product specifications and descriptions in this document are subject to change without notice. Always refer to Agilent Web site for the latest revision.
