Linksys X2000

Set up your modem-router as only a router

NOTE
Run the Setup CD-ROM to install the modem-router If you cannot
run the Setup CD-ROM, refer to the steps below
To set up your modem-router as a router:
1. Connect one end of the provided Ethernet cable to your computer's
Ethernet adapter and the other end to an Ethernet port on the back of
the modem-router
2. Connect one end of an Ethernet cable to the Cable port on the back of
the modem-router, then connect the other end to an available Ethernet/
LAN port on your modem
3. Connect one end of the power adapter cord to the Power port and the
other end to the electrical outlet
4. Power on the computer that you will use to configure the modem-router
5. The LEDs for Power, Wireless, and Ethernet (one for each connected
computer) should light up If not, make sure the modem-router is
powered on and the cables are securely connected
NOTE FOR USERS IN NEW ZEALAND
To set up the device, follow these instructions:
1. Access the Setup > Basic Setup screen
2. Select RFC 2364 PPPoA from the Encapsulation drop-down menu
3. For the Virtual Circuit ID, enter 0 for the VPI and 100 for the VCI
4. Select VC for Multiplexing
5. Select Multimode from the DSL Modulation drop-down menu
6. Enter your User Name and Password details from your ISP
7. Click Save Settings
Installation
8
