METAL PROBE

1. Metal probe tip
2. Metal probe connector wire

GETTING STARTED

BATTERY INSTALLATION

Please press RESET
after battery installation
or replacement.
1. Slide upwards to remove the
battery compartment cover.
2. Install two AA batteries in
the compartment as indicated by the polarity symbols
(+/-).
3. Return the battery compartment cover.

CONNECTING THE PROBE

You can use two probes
1
at the same time. To order
an extra probe, please
visit our website
2
www.oregonscientific.com.
To connect the probe
with the display unit:
• Carefully pull out the
rubber cap and then
plug the meat probe
into the socket.
The top socket is for channel one, the bottom socket
is for channel two.

PLACEMENT

To place display unit:
You can place the touch-key display unit on table or slide
out the stand to adjust a right angle for desktop placement.
4
