4.1 Product description and overview for collocation, Lille Viking 2000+
The overview shows Lille Viking 2000+. The models may vary, but they contain the same main parts as shown in the overview. If the sup-
porting motor you have received is different from what is shown here, please note the differences when you are having the supporting
motor demonstrated for you.
Control unit
7
8
Front fittings
12 13
Motor
1. Motor unit
2. Battery box
3. Strap handle
4. Transport securement (Included in UB4450101 & UB2022071)
Control unit
5. Coiled cable
6. Handle speed control
7. ON/ OFF knob
8. Knob
9. Attachment speed control (Included in UB4450101 & UB2022071) 18.

4. Product description and overview for collocation

9
6
5
19
10
11
Rear fitting
14
18
Motor
3 2 4
Front fittings
10. Steel bracket front
11. Pull bar bracket
12. Telescopic bar
13. Cross bar
Rear fitting
14. Mounting arm
15. Pressure part
16. Steel bracket rear
17. Disengaging handle
Quick release arm
19. Tie rod
39
Etac / Lille Viking / www.etac.com
15
16
17
1
