POCKET TRANSMITTER:

1
8
A
12
5 4 3 2
6
B
7
TRANSMITTER ANTENNA
1
To ensure optimal radio transmission, do not touch,
bend or cover the antenna.
INPUT
2
3 pin mini XLR input for headset, lavalier and instrument
microphones, as well as guitar cable. A list of all models
is located in the specifications.
MIC / 0 DB / -10 DB
3
Adjust the input sensitivity.
LDWSECO2: Adjust the sensitivity so that when a
signal is present (voice, vocals, guitar...), the green
signal LED (NORM) on the receiver lights up. As soon
as the red PEAK LED lights up, reduce the sensitivity
by turning the 3 stage MIC / 0 dB / -10 dB switch to
the next lowest value, otherwise unwanted distortion
may occur.
LDWSECO2X2: Adjust the sensitivity so that when a
signal is present (voice, vocals, guitar...), the green
signal LED (NORM) on the receiver lights up. As soon
as the audio signal begins to distort, reduce the
sensitivity by turning the 3 stage MIC / 0 dB / -10 dB
switch to the next lowest value.
ON / STANDBY / OFF
4
When the transmitter is turned on (switch is in
STANDBY / ON position), the red LED flashes briefly to
indicate the battery status and goes out immediately
if batteries with sufficient charge are inserted. In
STANDBY position, the transmitter is in operation, but
the audio signal is muted.
BATTERY STATUS LED
5
As soon as the red LED lights up to indicate the
battery status, replace the batteries immediately.
ATTACHING THE PACK TRANSMITTER
6
Attach the transmitter to a belt (Figure
strap (Figure ) as shown here.
B
) or guitar
A
