Luda Elektronik trailerCam Bedienungsanleitung Seite 29

LCD (display)
Power connection
*Mirror image, (Left, Right, Up, Down)
The mirror function turns the image the correct way, if the camera or monitor is mounted upside down,
or mirrors it if using the camera as a reversing cam.
**Channel selector, (CH1, CH2, CH3, CH4)
Select the channel corresponding to your camera's transmitting channel. The included camera is
fixed on channel 4.
***Brightness, Contrast.
Press the respective button to adjust the brightness or contrast.
Wireless 3.6" LCD-monitor.
Suction bracket for 3.6" LCD-monitor.
- 29 -
Antenna
On/Off
Mirror image*
Channel selector**
Brightness***
Contrast***
Suction cup
Locking lever
