While 4x4 is being activated, the display shows "4x4: shifting ON". After
successful switching the display shows "4x4: ON".
Driving in all-wheel drive mode:
As soon as the all-wheel drive is activated, the control lamp next to the
button lights up and the display shows "4x4: ON". Warning lamps in the
instrument cluster indicate that the ESP and ABS are deactivated. The
notices "CHECK ABS" and "CHECK ESP" are displayed on the text out-
put.
Function
1
Instrument cluster
Starting at a speed of 50 km/h, a beep sounds every 2 seconds. An addi-
tional display messages asks the drive to reduce speed.
78
Status
Symbols
Warning lamps for
deactivation ESP
and ABS
All-wheel drive deactivation:
The all-wheel drive can be deactivated at any time by pressing the
4-wheel-drive button "4x4".
During the switching process, the control panel shows "4x4: shifting OFF".
As soon as the red control lamp next to the 4-wheel-drive button "4x4"
turns off and the display shows "4x4: "OFF", the process is complete and
the vehicle is in 4x2 mode.
ESP is automatically reactivated after turning off the all-wheel
drive. In order for the system to initialize as quickly as possible,
the speed should be less than 20 km/h and pronounced stee-
ring or braking should be avoided. As soon as the signal lamps
in the instrument cluster turn off, the brake control system is fully
available again.
If the all-wheel drive cannot be turned on or off, the switching
process can be sped up in the following ways:
• Provoke a load change (start driving, brake)
• Drive in a slight curve
• Stop, briefl y put in reverse and start driving, drive a slight
curve if necessary, then drive forward again.
Errors activating the all-wheel drive are shown on the display of
the control panel in the centre console.
Operating Manual
All-wheel drive, gear reduction
BG
CS
DA
DE
EL
EN
ES
ET
FI
FR
HR
HU
IS
IT
LT
LV
NL
NO
PL
PT
RM
RU
SK
SL
SV
79
