2.2. Front Panel

2.3. Back Panel

1. Power indicator & button
2. USB indicator
3. Infrared receiver window
4. Main antenna
Mode
Working
Standby
1. Power input
2. Main antenna
3. Y/Pb/Pr OUT jack
4. A/V OUT jack
5. HDMI interface
6. eSATA port
7. Gigabit LAN socket
8. USB 3.0 & 2.0 Host port
9. S/PDIF Optical jack
8
English
Status
Blue
Red
