ZECK wireless system · made in Germany
owner´s manual d.a.i.sy wireless system, © Zeck Audio 8/96
owner´s manual
Quick reference
Transmitter
1
input gain (sensitivity) adjusting screw
2
battery check LED
3
on/off switch for transmitter
4
battery recess cover
5
safety lock for XLR-plug
R
6
battery terminals
7
POWER
transmitter unit ID tag with channel number, operating frequency,
and serial number
Receiver
8
antennas
9
'mute' (noise suppression) adjusting screw
10
'RF receive' indicator
16
17
11
'low'
12
'o.k.'
13
'clip'
B
A 112
Z
351 E RF
14
T
power on/off switch for receiver
15
ac supply cord
16
XLR output
17
jack output
18
receiver unit ID tag with channel number, operating frequency, and
serial number
19
output level control
owner´s manual d.a.i.sy wireless system, © Zeck Audio 8/96
} }
audio level check indicator
