Modified Sine Wave
Note
Note when connecting devices with an electrical drive (such as power drills
and refrigerators), that they often require more power than the data is
indicated on the type plate.
5

Connecting the inverter

5.1

Fastening the inverter

You can fasten the inverters (INV300N, INV600N, INV100N0, INV1500N and INV2000N) by
screwing through the holes on the underside.
When selecting the installation location, observe the following instructions:
● The inverter can be mounted horizontally or vertically.
● The inverter must be installed in a place that is protected from moisture.
● The inverter may not be installed in the presence of flammable materials.
● The inverter may not be installed in a dusty environment.
● The place of installation must be well-ventilated. A ventilation system must be present for
installations in small, closed spaces. The minimum clearance around the inverter must
be at least 25 cm.
● The air intake on the front side or the air outlet on the back of the inverter must remain
clear.
● For ambient temperatures higher than 40°C (such as in engine or heating compartments,
or direct sunlight). The heat from the inverter under load can lead to the automatic
shut-off of the inverter.
● The installation surface must be level and sufficiently sturdy.
Caution
Before drilling any holes, ensure that no electrical cables or other parts of the
vehicle can be damaged by drilling, sawing and filing.
8
Technical description
