Even though the original CPU fits tightly in the slot, excessive force should not be needed
to remove it. If resistance is felt, try alternatively pulling on each edge of the board to
gently "rock" it loose.
The MACCELERATE!750 accelerator board has to be plugged into the empty CPU slot.
Make sure, the cooling cap of the MACCELERATE!750 is facing to the right (Picture 7).
Picture 8
Installation of the
MACCELERATE!750
accelerator board
Insert the board by carefully pushing down on its upper edge (Picture 8). As when remo-
ving, excessive force should not be required. Ensure the board is aligned properly if at first
it does not slide in easily. When fitted, the board should have a firm fit.
18
MACCELERATE!750 User manual
Picture 6
Picture 7
