phase 5 MACCELERATE!750 Anwenderhandbuch Seite 17

MACCELERATE!750 User manual
From the top view as shown in picture 3, you will find grey plastic cover. This plastic cover
has to be pulled upwards to the left as shown in picture 4.
The CPU slot with the original Macintosh CPU board is now visible (Picture 5). The original
CPU board has to be removed by carefully pulling it upwards (Picture 6).
Picture 5
Position of the
CPU expansion slot in
the Power Macintosh
7500/100
Picture 3 Picture 4
17
