SAFETY INSTRUCTIONS/WARNING
Read and follow all instructions and warnings before use.
• WARNING: PINCH POINT! KEEP HANDS CLEAR OF SUPPORT BARS DURING OPERATION. SERIOUS INJURY
MAY OCCUR.
• DO NOT EXCEED MAXIMUM STATED WEIGHT CAPACITY. SERIOUS INJURY OR PROPERTY DAMAGE MAY
OCCUR.
• CAUTION: Lift hazard! Two people are required to move workstation. Serious injury may occur.
• Keep cables clear of support bars during operation, follow the cable routing instruction in this manual.
Failure to follow these instructions may result in equipment damage or personal injury.
• DO NOT lean on the keyboard platform.
• DO NOT adjust counter balance until all equipment and accessories have been placed on the workstation.
• DO NOT raise or lower the platform too quickly. Raising and lowering the platform too quickly may cause
an unstable situation for equipment resulting in personal injury or property damage.
• Only compatible with Fellowes Monitor Arm Kit for Lotus.
• Make sure the desk or mounting surface is level and can support the combined weight of the workstation
and accessories.
• Remove all equipment and accessories from the workstation before moving.
• Manufacturer certifies that product meets or exceeds applicable ANSI/BIFMA standards.
• Use Velcro if not using monitor arms. Velcro is single use.
CONTENTS
Workstation
Only compatible with Fellowes Monitor Arm Kit for Lotus. Visit www.Fellowes.com for more information.
SET-UP
STEP 1
Use 2 people to place the sit stand on your desk. Be sure that the front
edge of the keyboard platform aligns with the desk edge.
2
Lotus_SitStand_872199_10L_102816_RevB.indd 2-3
ENGLISH
Lotus™ Sit Stand Workstation
≤ 13.6 Kg
≤ 30 lbs
≤ 2.2 Kg
≤ 5 lbs
Cord Funnel Cable zip/tool
STEP 2
Place your monitor, keyboard and mouse on the workstation. Use
the enclosed Velcro to secure the monitor(s) to the workstation.
Leave the monitor cover plate in place unless using the Fellowes
Monitor Arm Kit for Lotus.

CORD MANAGEMENT

Ensure the workstation is at the highest position. Follow all cord routing instructions to ensure cables are not pinched by the support bars. Make sure
the cables are long enough to accommodate the full range of motion (17"/432mm).
STEP 1
Route the keyboard and mouse cords through the opening in the keyboard platform. Be sure to anchor the cords with the clip on the underside of the
platform. Failure to follow these instructions may result in equipment damage or personal injury.
Velcro
STEP 2A
Continue routing the cords around the workstation through the cord channel to the rear. Insert the cord funnel in 1 of 3 locations on the cord channel.
Choose the location that will best accommodate your setup.
STEP 3
Using both hands, push down slightly and engage both levers to
raise the workstation to the highest position.
10/28/16 2:35 PM
3
