Technical specifications

Downstream signal path
Frequency range
Return loss
Gain
Input attenuator control range
Input equaliser control range
Cable simulator
Mid-stage slope
Mid-stage gain
Flatness
Test point input / output
Noise figure
U
max(112 QAM channels)
Output level, CTB CENELEC 41 ch
Output level, CSO CENELEC 41 ch
Output level, XMOD CENELEC 41 ch
Upstream signal path
Frequency range
Return loss
Gain
Input / output gain control
Output equaliser
Flatness
Return test point
Noise figure
Output level, DIN 45004B
BER | MER
General
Power consumption (high gain / low gain)
Supply voltage
Input / Output connectors
Test point connector
Dimensions (h x w x d)
Weight
Operating temperature
Class of enclosure
EMC combatibility | Safety
Additional EMC tests for RF ports
All specifications are subject to change without notice
User Manual
59300460
17.12.2013
85...1006 MHz
18 dB
40 / 32 dB
0...-20 dB, 1 dB step
0...22 dB, 1 dB step
0...9 dB, 1 dB step
0...10 dB, 1 dB step
0...-10 dB, 1 dB step
± 0.5 dB
-20 dB
5.5 dB
109.5 dBuV
112.0 dBμV
113.0 dBμV
109.0 dBμV
5... 65 MHz
18 dB
32 / 22 dB
0...-20 dB, 1 dB step
0...12 dB, 1 dB step
± 0.8 dB
-20 dB
3.7 dB
119.0 dBµV
-8
< 1 x 10 | > 35 dB
14.5 W / 13.5 w
26... 65 V AC / 180...255 V AC
PG11 (several adaptors available)
F female
182 (210) mm x 140 (148) mm xx 84 mm
1.5 kg
-40...+55 °C
IP 54
EN 60728-2 | EN 60728-11
ESD 4 kV / Surge 6 kV
CXE280
Rev.002
4(20)
