3. Scope of delivery

The c-Go will be supplied with the following components:
1. High quality plastic housing
2. One three-wire cable:
black wire: ground connector
•
red wire: battery charging line voltage supply
•
• orange wire: vehicle battery connection via the 12V caravan system
3. Mains cable for connection to the public power supply
4. Two LEDs to display the unit's operating condition
5. Battery connection cable with crocodile clips
6. Battery connection cable with ring cable lugs
7. Jumper to change the charging characteristics
8. Assembly instructions and operating manual

4. Mounting and installation

The charger is not designed for outdoor use. Use only indoors in sufficiently ventilated
rooms. Always provide for sufficient cooling. Insufficient cooling will automatically lead
to a reduction in output power. Do not expose the unit to direct sunlight.
The 20A version is equipped with an additional internal low-noise fan. The fan will be
activated automatically when the temperature inside the unit reaches a specific level.
3
2
4
1
