Operating Manual System LIFEBOOK Bay Projector...
Seite 2
For automatic driver updates, please go to: http://support.ts.fujitsu.com/com/support/index.html Should you have any technical questions, please contact: ● our Hotline/Service Desk (see Service Desk list or visit: http://ts.fujitsu.com/support/servicedesk.html) ● your sales partner ● your sales office We hope you really enjoy using your new Fujitsu system.
Seite 4
Brand names may be protected trademarks of the respective manufacturer and/or protected by copyright. Their use by third parties for their own purposes could represent a violation of the rights of the owner. For more information, see http://ts.fujitsu.com/terms_of_use.html Order No. Fujitsu Technology Solutions: A26391-F954-Z320-1-8N19, Edition 1...
Seite 5
LIFEBOOK Bay Projector Operating Manual English Deutsch Français Italiano Español...
Installing drivers............................ 9 Installing the Bay Projector......................... 10 Removing the Bay Projector....................... 11 Working with the Bay Projector ...................... 12 Switching on the Bay Projector......................12 Adjusting projection angles and image rotation.................. 13 Using the focus wheel to adjust image sharpness ................14 Switching display modes ........................
Seite 8
English - Contents Fujitsu Technology Solutions...
At the end of a long day for business travellers, the Bay Projector can also double-up as a hotel room personal cinema, where it can be used for playing back movies on a bigger screen, providing more comfortable viewing.
This chapter presents the individual hardware components of your device. It gives an overview of the indicators and ports of the device. Please familiarise yourself with these components before you start to work with the device. Laser lens Release lever Air vents Focus wheel Projector Control buttons Fujitsu Technology Solutions...
Description Room temperature is about to grow too Blinking Green, solid high, please pay attention. The Bay Projector is to hot. Let it cool Blinking Orange, solid down before putting it into operation again. A problem has occurred. Retract the...
2 sec Colour Orange. Green When the Projector is switched on, the Laser On/Off button lights up orange. Status of laser Laser brightness 30 lm 20 lm (Battery) Laser brightness 40 lm 30 lm (AC adapter) Fujitsu Technology Solutions...
This may lead to burns. • Do not put items close to the air vents of the Bay Projector or block the air vents while the Bay Projector is running. The Bay Projector may overheat. Fire hazard! •...
Important notes General information concerning operation • This device cannot display protected content. • Windows XP operating systems: The Bay Projector cannot project 3D content or DirectX-based games. • Hardware acceleration is not supported. • There may be stuck and/or dead pixels in the projected image. This does not represent a malfunction.
First-time setup of your device English - First-time setup of your device Installing drivers ► Insert the Bay Projector Driver CD/DVD in the optical drive of your notebook. ► Insert the driver's CD/DVD in an external CD/DVD drive. For Windows 7: ►...
Ensure that the notebook bay is empty. ► Push the Bay Projector into the notebook bay. In case of LIFEBOOK S Series, the bottom of the Bay Projector is not level with the bottom of the LIFEBOOK itself (see circle): Fujitsu Technology Solutions...
First-time setup of your device English - Removing the Bay Projector ► Before removing the Bay Projector, retract the Bay Projector into the notebook bay. ► Close the LCD screen of the notebook. ► Remove all the cables from the notebook.
Working with the Bay Projector Switching on the Bay Projector ► To unlock the Bay Projector, slide the release lever in the direction of the arrow. ► Pull the Bay Projector out of the bay until you can see the control buttons.
Press the Laser On/Off button. The laser is switched on. The Laser On/Off button lights up green. Adjusting projection angles and image rotation ► If necessary, adjust the angle of the Bay Projector to between 0 and 90 angular degrees. Fujitsu Technology Solutions...
English - Working with the Bay Projector Using the focus wheel to adjust image sharpness ► To adjust image sharpness, scroll the focus wheel (1) up or down. Fujitsu Technology Solutions...
Working with the Bay Projector English - Switching display modes You can select the display mode of your notebook and your Bay Projector. Use the display mode functionality of your respective Windows operating system: Display Description Option in Windows 7...
Press the Laser On/Off button. The Laser On/Off Button changes to orange. The laser is turned off. ► Lower the Bay Projector until it reaches 0 angular degrees (1). ► Retract the Bay Projector into the notebook bay (2). The Bay Projector is turned off.
This section helps you to resolve problems you may encounter while setting up or using the Bay Projector. Some problems may not be directly linked to the Bay Projector. Therefore, also check any other equipment connected to your notebook. If you are not able to solve a particular problem, please contact your distributor or Fujitsu Service Desk.
English - Technical data Technical data Bay Projector for Bay Projector for LIFEBOOK S761 LIFEBOOK P771 Resolution 800 x 600 pixels Image size (Projection 15 inches to 75 inches (0.5 m to 2.5 m) distance) Brightness 40 lm / 30 lm (AC Adapter)
Seite 25
Treiberinstallation ..........................9 Einbau des Bay Projectors ......................... 10 Ausbau des Bay Projectors ........................ 11 Arbeiten mit dem Bay Projector ...................... 12 Einschalten des Bay Projectors......................12 Einstellung von Projektionswinkel und Bilddrehung ................13 Verwendung des Fokusrads zum Scharfstellen ................. 14 Umschalten zwischen Display-Modi ....................
Seite 26
Deutsch - Inhalt Fujitsu Technology Solutions...
Deutsch - Innovative Technologie Ihr Bay Projector ist der weltweit erste Projektor, der in den modularen Schacht der Notebooks LIFEBOOK P771 und LIFEBOOK S761 eingebaut werden kann. Der ausklappbare Bay Projector kann innerhalb von Sekunden verwendet werden und macht Ihr Notebook noch komfortabler und mobiler: Sie können Ihren Kollegen und Freunden Präsentationen, Tabellenkalkulationen oder...
In diesem Kapitel werden die einzelnen Hardwarekomponenten des Geräts vorgestellt. Es enthält eine Übersicht über Anzeigen und Anschlüsse des Geräts. Machen Sie sich vor der Arbeit mit dem Gerät mit diesen Komponenten vertraut. Laserobjektiv Entriegelung Lüftungsöffnungen Fokusrad Projektor Bedienungstasten Fujitsu Technology Solutions...
Die Beleuchtung der Bedienungstasten liefert weitere Informationen über den Zustand des Bay Projectors. Beschreibung Zimmertemperatur ist im Grenzbereich, Blinken Grün, leuchtet bitte beachten. Der Bay Projector ist zu heiß. Lassen Sie Blinken Orange, leuchtet ihn vor erneuter Inbetriebnahme abkühlen. Ein Problem ist aufgetreten. Schieben Sie Blinken Orange, blinkt den Projektor wieder hinein.
Berühren Sie das Objektiv des Bay Projectors nicht. Der Rand der Objektivlinse ist heiß und scharf - Verletzungsgefahr! • Verwenden Sie das Notebook und den Bay Projector nicht auf instabilem Untergrund oder in einer feuchten oder staubigen Umgebung. • Berühren Sie den Anschluss des Bay Projectors nicht.
Wichtige Hinweise Allgemeine Informationen zum Betrieb • Dieses Gerät kann keine geschützten Inhalte wiedergeben. • Für Windows XP-Betriebssysteme: Der Bay Projector kann keine 3D-Inhalte oder auf DirectX basierende Spiele darstellen. • Hardwarebeschleunigung wird nicht unterstützt. • Im projizierten Bild können ständig leuchtende oder ständig schwarze Pixel auftreten. Dabei handelt es sich nicht um eine Fehlfunktion.
Beachten Sie während der Installation die folgenden Punkte: • Brechen Sie den Installationsprozess nicht ab. • Starten Sie keine andere Softwareanwendung. • Schalten Sie Ihr Notebook nicht ab. ► Starten Sie nach Abschluss der Installation Ihr Notebook neu, wenn Sie dazu aufgefordert werden. Fujitsu Technology Solutions...
► Stellen Sie sicher, dass der Notebookschacht leer ist. ► Schieben Sie den Bay Projector in den Notebookschacht. Bei der LIFEBOOK-S-Serie schließt die Unterseite des Bay Projectors nicht eben mit der Unterseite des LIFEBOOK selbst ab (siehe Kreis): Fujitsu Technology Solutions...
Inbetriebnahme Ihres Geräts Deutsch - Ausbau des Bay Projectors ► Schieben Sie den Bay Projector in den Notebookschacht, bevor Sie ihn ausbauen. ► Schließen Sie den LCD-Bildschirm Ihres Notebooks. ► Entfernen Sie alle Kabel von Ihrem Notebook. ► Drehen Sie das Notebook um und legen Sie es auf eine stabile, ebene und saubere Oberfläche.
Arbeiten mit dem Bay Projector Arbeiten mit dem Bay Projector Einschalten des Bay Projectors ► Schieben Sie die Entriegelung in Pfeilrichtung, um den Bay Projector zu entriegeln. ► Ziehen Sie den Bay Projector heraus, bis Sie die Bedienungstasten sehen können. Fujitsu Technology Solutions...
Arbeiten mit dem Bay Projector Deutsch - Der Bay Projector wird automatisch eingeschaltet. Die Laser Ein/Aus-Taste leuchtet orange. ► Drücken Sie die Laser Ein/Aus-Taste. Der Laser wird eingeschaltet. Die Laser Ein/Aus-Taste leuchtet grün. Einstellung von Projektionswinkel und Bilddrehung ► Gegebenenfalls kann der Winkel des Bay Projectors zwischen 0° und 90° eingestellt werden.
Deutsch - Arbeiten mit dem Bay Projector Verwendung des Fokusrads zum Scharfstellen ► Drehen Sie das Fokusrad (1) nach oben oder unten, um die Bildschärfe einzustellen. Fujitsu Technology Solutions...
Arbeiten mit dem Bay Projector Deutsch - Umschalten zwischen Display-Modi Sie können die Display-Modi Ihres Notebooks und Ihres Bay Projectors wählen. Verwenden Sie hierzu die jeweilige Funktion Ihres Windows-Betriebssystems: Display- Beschreibung Option in Windows 7 Option in Windows Modus Multidisplay...
Drücken Sie die Laser Ein/Aus-Taste. Die Laser Ein/Aus-Taste wechselt auf orange. Der Laser ist ausgeschaltet. ► Klappen Sie den Bay Projector (1) auf 0° herunter. ► Schieben Sie den Bay Projector in den Notebookschacht (2). Der Bay Projector ist nun ausgeschaltet.
Dieser Abschnitt hilft Ihnen dabei, Probleme beim Einrichten oder bei der Benutzung des Bay Projectors zu beheben. Manche von diesen Problemen hängen möglicherweise nur indirekt mit dem Bay Projector zusammen. Überprüfen Sie also auch jegliches übrige Zubehör, das an Ihr Notebook angeschlossen ist.
Seite 42
Problem Lösung des Problems Die Zimmertemperatur ist zu niedrig. Die projizierte Anzeige ist Blau. ► Stellen Sie Ihren Bay Projector an einem anderen Ort auf. ► Stellen Sie die Bildschärfe ein, siehe Kapitel Das Bild ist unscharf. "Verwendung des Fokusrads zum Scharfstellen".
Technische Daten Deutsch - Technische Daten Bay Projector für Bay Projector für LIFEBOOK S761 LIFEBOOK P771 Auflösung 800 x 600 Pixel Bilddiagonale 15 bis 75 Zoll (0,5 bis 2,5 m) (Projektionsabstand) Helligkeit 40 lm / 30 lm (Netzbetrieb) 30 lm / 20 lm (Akkubetrieb) Trapezeinstellung Manuell / automatisch 0°...
Seite 44
Deutsch - Technische Daten Fujitsu Technology Solutions...
Seite 45
Dépose du Bay Projector........................11 Utilisation du Bay Projector......................12 Mise sous tension du Bay Projector ....................12 Réglage des angles de projection et de la rotation de l'image ............14 Utilisation de la molette de mise au point pour régler la netteté de l'image ........15 Commutation des modes d'affichage ....................
Seite 46
Français - Sommaire Fujitsu Technology Solutions...
Français - Technologie innovante Votre Bay Projector est le premier projecteur au monde à être intégré dans une baie de notebook modulaire pour LIFEBOOK P771 et LIFEBOOK S761. Le Bay Projector escamotable est prêt à l'emploi en quelques secondes et ajoute de la commodité et de la mobilité à votre notebook : aucun vidéoprojecteur externe ou câble externe n'est nécessaire pour partager des diapositives, des...
Ce chapitre présente les différents composants matériels de votre système. Il donne une vue d'ensemble des indicateurs et ports du projecteur. Veuillez vous familiariser avec ces composants avant de l'utiliser pour la première fois. Lentille laser Levier de déblocage Fentes d'aération Molette de mise au point Projecteur Boutons de commande Fujitsu Technology Solutions...
Bay Projector. Description Attention, la température ambiante va Clignotant Vert, continu bientôt atteindre un niveau excessif. Le Bay Projector est trop chaud. Le Clignotant Orange, continu laisser refroidir avant de le remettre en service. Un problème s'est produit. Rentrez la...
Orange. Vert A la mise sous tension du projecteur, le bouton marche/arrêt du laser s'allume en orange. Etat du laser Luminosité du 30 lm 20 lm laser (batterie) Luminosité du 40 lm 30 lm laser (adaptateur secteur) Fujitsu Technology Solutions...
Bay Projector pendant son fonctionnement. Risque de surchauffe du Bay Projector. Risque d'incendie ! • Ne touchez pas la lentille du Bay Projector. Les bords de la lentille sont chauds et coupants. Risque de blessures. •...
• Cet appareil ne peut pas afficher un contenu protégé. • Systèmes d'exploitation Windows XP : Le Bay Projector ne peut pas projeter un contenu 3D ou des jeux basés sur DirectX. • L'accélération matérielle n'est pas prise en charge.
Français - Première utilisation du système Installation des pilotes ► Insérez le CD/DVD du pilote du Bay Projector dans le lecteur optique de votre notebook. ► Insérez le CD/DVD dans un lecteur de CD/DVD externe. Pour Windows 7 : ►...
► Enfoncez le Bay Projector dans la baie du notebook. Si le notebook est de type LIFEBOOK S, la base du Bay Projector n'est pas au même niveau que la base du LIFEBOOK lui-même (voir cercle) : Fujitsu Technology Solutions...
Première utilisation du système Français - Dépose du Bay Projector ► Avant de déposer le Bay Projector, rentrez-le dans la baie du notebook. ► Fermez l'écran LCD du notebook. ► Retirez tous les câbles du notebook. ► Retournez le notebook et placez-le sur une surface stable, propre et plate. Si nécessaire, placez un tissu antidérapant sur cette surface pour ne pas rayer le périphérique.
Français - Utilisation du Bay Projector Utilisation du Bay Projector Mise sous tension du Bay Projector ► Pour débloquer le Bay Projector, faites glisser le levier de déblocage dans le sens de la flèche. Fujitsu Technology Solutions...
Seite 57
Utilisation du Bay Projector Français - ► Retirez le Bay Projector de la baie jusqu'à ce que vous puissiez voir les boutons de commande. Le Bay Projector se met automatiquement sous tension. Le bouton marche/arrêt du laser s'allume en orange.
Français - Utilisation du Bay Projector Réglage des angles de projection et de la rotation de l'image ► Si nécessaire, réglez l'angle du Bay Projector à une valeur entre 0 et 90 degrés. Fujitsu Technology Solutions...
Utilisation du Bay Projector Français - Utilisation de la molette de mise au point pour régler la netteté de l'image ► Pour régler la netteté de l'image, tournez la molette de mise au point (1) vers le haut ou le bas.
Français - Utilisation du Bay Projector Commutation des modes d'affichage Vous pouvez sélectionner le mode d'affichage de votre notebook et de votre Bay Projector. Utilisez la fonctionnalité de mode d'affichage de votre système d'exploitation Windows : Mode Description Option dans Windows 7...
Appuyez sur le bouton marche/arrêt du laser. Le bouton marche/arrêt du laser devient orange. Le laser est éteint. ► Abaisser le Bay Projector jusqu'à un angle de 0 degré (1). ► Rentrez le Bay Projector dans la baie du notebook (2).
Cette section vous aide à résoudre les problèmes susceptibles d'être rencontrés pendant l'installation ou l'utilisation du Bay Projector. Certains peuvent ne pas être directement liés au Bay Projector. Par conséquent, vérifiez aussi tout autre matériel raccordé à votre notebook. Si vous n'êtes pas en mesure de résoudre un problème particulier, veuillez contacter votre distributeur ou Service Desk Fujitsu.
Caractéristiques techniques Français - Caractéristiques techniques Bay Projector pour Bay Projector pour LIFEBOOK S761 LIFEBOOK P771 Résolution 800 x 600 pixels Taille d'image 0,5 à 2,5 m (15 à 75 pouces) (distance de projection) Luminosité 40 lm / 30 lm (adaptateur secteur) 30 lm / 20 lm (batterie) Correction du trapèze...
Seite 64
Français - Caractéristiques techniques Fujitsu Technology Solutions...
Seite 65
Trasporto e posizionamento del dispositivo ..................7 Informazioni generali sul funzionamento ....................8 Impostazione iniziale del dispositivo....................9 Installazione dei driver.......................... 9 Installazione del Bay Projector ......................10 Rimozione del Bay Projector ......................11 Utilizzo del Bay Projector......................... 12 Accensione del Bay Projector......................12 Regolazione dell'angolazione di proiezione e della rotazione dell'immagine ........
Seite 66
Italiano - Sommario Fujitsu Technology Solutions...
Projector Bay è più silenzioso e più robusto di un proiettore tradizionale, le cui lampadine per obiettivo sono facilmente danneggiabili. Al termine di una lunga giornata per i viaggiatori d’affari, il Bay Projector può anche trasformare una camera d’albergo in una sala cinematografica personale, ed essere quindi utilizzato per riprodurre i filmati su uno schermo più...
Si invita l'utente ad acquisire dimestichezza con tali componenti prima di iniziare a utilizzare il dispositivo. Lente laser Leva di sblocco Prese d'aria Ghiera di messa a fuoco Proiettore Pulsanti di comando Fujitsu Technology Solutions...
Projector. Descrizione La temperatura ambiente sta per Lampeggiante Verde, costante raggiungere un livello troppo elevato, prestare attenzione. Il Bay Projector è troppo caldo. Farlo Lampeggiante Arancione, raffreddare prima di utilizzarlo costante nuovamente. Si è verificato un problema. Riporre la Lampeggiante Arancione, parte del proiettore nel notebook.
Colore Arancione. Verde In caso di proiettore acceso, il pulsante On/Off del laser si accende in arancione. Stato del laser Disattivato Attivato Luminosità laser 30 lm 20 lm (batteria) Luminosità laser 40 lm 30 lm (adattatore CA) Fujitsu Technology Solutions...
Non toccare le lenti del Bay Projector in quanto i bordi sono caldi e affilati e potrebbero provocare infortuni. • Non utilizzare il notebook e il Bay Projector su una superficie instabile e in un ambiente umido o polveroso. •...
Informazioni generali sul funzionamento • Questo dispositivo non può visualizzare contenuti protetti. • Sistemi operativi Windows XP: il Bay Projector non è in grado di proiettare contenuti 3D o giochi basati su DirectX. • L'accelerazione hardware non è supportata. •...
Impostazione iniziale del dispositivo Italiano - Impostazione iniziale del dispositivo Installazione dei driver ► Inserire il CD/DVD del driver Bay Projector nell'unità ottica del notebook. Oppure ► Inserire il CD/DVD del driver in un'unità CD/DVD esterna. Per Windows 7: ►...
Assicurarsi che il vano del notebook sia vuoto. ► Spingere il Bay Projector nel vano del notebook. Nel caso della serie S LIFEBOOK, la parte inferiore del Bay Projector non è a livello di quella del LIFEBOOK (vedere parte cerchiata in figura): Fujitsu Technology Solutions...
Impostazione iniziale del dispositivo Italiano - Rimozione del Bay Projector ► Prima di rimuovere il Bay Projector, ritrarre il Bay Projector nel vano del notebook. ► Chiudere lo schermo LCD del notebook. ► Rimuovere tutti i cavi collegati al notebook.
Italiano - Utilizzo del Bay Projector Utilizzo del Bay Projector Accensione del Bay Projector ► Per sbloccare il Bay Projector, fare scorrere la leva di sblocco nella direzione indicata dalla freccia. Fujitsu Technology Solutions...
Seite 77
Utilizzo del Bay Projector Italiano - ► Estrarre il Bay Projector dal vano finché è possibile vedere tutti i pulsanti di comando. Il Bay Projector si accende automaticamente. Il pulsante On/Off del laser si accende in arancione. ► Premere il pulsante On/Off del laser.
Italiano - Utilizzo del Bay Projector Regolazione dell'angolazione di proiezione e della rotazione dell'immagine ► Se necessario, regolare l'angolazione del Bay Projector tra 0 a 90 gradi. Fujitsu Technology Solutions...
Utilizzo del Bay Projector Italiano - Utilizzo della ghiera di messa a fuoco per la regolazione della nitidezza immagine ► Per regolare la nitidezza dell'immagine, girare la ghiera di messa a fuoco (1) su e giù. Fujitsu Technology Solutions...
Italiano - Utilizzo del Bay Projector Commutazione delle modalità di visualizzazione È possibile selezionare la modalità di visualizzazione del notebook e del Bay Projector. Utilizzare la funzionalità delle modalità di visualizzazione del sistema operativo Windows in uso: Modalità di Descrizione...
Premere il pulsante On/Off del laser. Il pulsante On/Off del laser diventa arancione. Il laser viene spento. ► Abbassare il Bay Projector finché l'angolazione è pari a 0 gradi (1). ► Riporre il Bay Projector nel vano del notebook (2).
Questa sezione supporta l'utente nella risoluzione dei problemi che possono verificarsi durante l'impostazione e l'utilizzo del Bay Projector. Alcuni problemi potrebbero non essere direttamente associati al Bay Projector. Pertanto, controllare anche eventuali altri dispositivi collegati al notebook. Se non è possibile risolvere un determinato problema, contattare il distributore o il Service Desk Fujitsu.
Seite 83
Risoluzione dei problemi La temperatura ambiente è troppo bassa. Immagine proiettata blu ► Selezionare un'altra collocazione per il Bay Projector. ► Regolare la nitidezza dell'immagine; vedere il capitolo Immagine non nitida "Utilizzo della ghiera di messa a fuoco per la regolazione della nitidezza immagine".
Italiano - Dati tecnici Dati tecnici Bay Projector per Bay Projector per LIFEBOOK S761 LIFEBOOK P771 Risoluzione 800 x 600 pixel Dimensione Da 15 a 75 pollici (da 0,5 m a 2,5 m) dell'immagine (distanza proiezione) Luminosità 40 lm/30 lm (adattatore CA)
Seite 85
Uso de la rueda de enfoque para ajustar la nitidez de la imagen ............16 Cambio entre modos de pantalla......................17 Apagado del proyector integrado ....................... 18 Preguntas frecuentes - FAQ ......................19 Datos técnicos ..........................21 Fujitsu Technology Solutions...
Seite 86
Español - Índice Fujitsu Technology Solutions...
LIFEBOOK. Cuando no se utiliza, el proyector integrado se puede retirar fácilmente para sustituirlo por una segunda batería modular, una unidad de DVD multiformato, o sencillamente para aligerar el portátil. Las imágenes de este manual corresponden al LIFEBOOK S761. Fujitsu Technology Solutions...
Indica información que aparece en pantalla. Este tipo de letra Indica nombres de programas, comandos o elementos de menú. Este tipo de letra Las "comillas" Indican los títulos de los capítulos, nombres de soportes de datos y términos que desean destacarse. Fujitsu Technology Solutions...
En este capítulo se presentan los distintos componentes del dispositivo. Proporciona una descripción general de los indicadores y puertos del dispositivo. Familiarícese con estos componentes antes de utilizar el dispositivo. Objetivo láser Palanca de desbloqueo Salidas de aire Rueda de enfoque Proyector Botones de control Fujitsu Technology Solutions...
Se ha producido un problema. Repliegue Parpadeando Naranja, la parte correspondiente al proyector. parpadeando Si el problema persiste y el botón no deja de parpadear, póngase en contacto con la asistencia técnica de Fujitsu. Fujitsu Technology Solutions...
Cuando se enciende el proyector, el botón de encendido/apagado del láser se ilumina en color naranja. Estado del láser Desactivado Activado Brillo del láser 30 lm 20 lm (batería) Brillo del láser 40 lm 30 lm (adaptador de CA) Fujitsu Technology Solutions...
Antes de extraer o replegar el proyector integrado, coloque el portátil sobre un escritorio u otra superficie estable y nivelada. • Antes de transportar el portátil, empuje de nuevo el proyector integrado dentro del compartimento. De lo contrario, las vibraciones y los golpes pueden dañar el proyector integrado. Fujitsu Technology Solutions...
DirectX. • No admite aceleración de hardware. • Es posible que haya píxeles fijos en un color y/o apagados en la imagen proyectada. Esto no representa una anomalía. Los píxeles efectivos son como mínimo el 99,99%. Fujitsu Technology Solutions...
Durante la instalación, asegúrese de lo siguiente: • No cancele el proceso de instalación. • No inicie ninguna otra aplicación de software. • No apague el portátil. ► Una vez completada la instalación, reinicie el portátil cuando se le solicite. Fujitsu Technology Solutions...
Empuje el proyector integrado en el compartimento del portátil. En el caso de la serie LIFEBOOK S, la parte inferior del proyector integrado no queda al mismo nivel que la parte inferior del propio LIFEBOOK (véase el círculo): Fujitsu Technology Solutions...
► Deslice el mecanismo de desbloqueo (1) en la dirección de la flecha y manténgalo así. ► Tire del proyector integrado (2) y extráigalo del compartimento del portátil. Fujitsu Technology Solutions...
Trabajo con el proyector integrado Español - Trabajo con el proyector integrado Encendido del proyector integrado ► Para desbloquear el proyector integrado, deslice la palanca de desbloqueo en la dirección de la flecha. Fujitsu Technology Solutions...
Seite 98
El proyector integrado se enciende automáticamente. El botón de encendido/apagado del láser se ilumina en color naranja. ► Pulse el botón de encendido/apagado del láser. El láser se enciende. El botón de encendido/apagado del láser se ilumina en color verde. Fujitsu Technology Solutions...
Trabajo con el proyector integrado Español - Ajuste de los ángulos de proyección y rotación de la imagen ► Si es necesario, ajuste el ángulo del proyector integrado entre 0 y 90 grados. Fujitsu Technology Solutions...
Trabajo con el proyector integrado Uso de la rueda de enfoque para ajustar la nitidez de la imagen ► Para ajustar la nitidez de la imagen, gire la rueda de enfoque (1) hacia arriba o hacia abajo. Fujitsu Technology Solutions...
Proyector Muestra únicamente la Desconectar Mostrar el Proyector apagado apagado imagen en el portátil. El proyector escritorio en proyector se apaga al la pantalla pulsar el botón de principal encendido/apagado del láser. Fujitsu Technology Solutions...
El botón de encendido/apagado del láser cambia a color naranja. El láser se desactiva. ► Baje el proyector integrado hasta que quede a 0 grados (1). ► Repliegue el proyector integrado en el compartimento del portátil (2). El proyector integrado se apaga. Fujitsu Technology Solutions...
Es posible que algunos problemas no estén directamente relacionados con el proyector integrado. Por tanto, compruebe también cualquier otro equipo conectado al portátil. Si no puede resolver algún problema en particular, póngase en contacto con su distribuidor o con la asistencia técnica de Fujitsu. Problema Solución de problemas El proyector integrado no se ►...
Seite 104
► Seleccione otra ubicación para instalar el proyector integrado. ► Ajuste la nitidez de la imagen; véase el capítulo "Uso La imagen no es nítida de la rueda de enfoque para ajustar la nitidez de la imagen". Fujitsu Technology Solutions...
Temperatura de almacenamiento: -10 a 60 °C/20 a 80% HR (sin condensación) Dimensiones 132,4 mm x 139,7 mm x 21,5 mm 130,1 mm x 135,3 mm x 15,9 mm exteriores (incluidas las partes que sobresalen): Largo x ancho x alto Peso 220 g Fujitsu Technology Solutions...
