Specifi cations:
Transmitter:
Operating frequency band
- VID-TRANS75KN
- VID-TRANS575KN
Output level
Modulation
Channel (4CH)
Video input level
Audio input level
Input port
Output port
Antenna
IR–remote IR output
Infrared emission carrier
Built in TV tuner
Standard
Memory
Power consumption
Dimension
Weight
Receiver:
Operating frequency band
- VID-TRANS75KN
- VID-TRANS575KN
Channel (4CH)
Video output level
Audio output level
Output port
Antenna
IR-transmit frequency
Infrared frequency input
Power consumption
Dimension
Weight
System:
Operational range: up to 100 meter (open fi eld), indoor max. 30 meter.
Remote control range: up to 50 meter (open fi eld), indoor max. 30 meter.
Actual range depends on environmental circumstances.
2.400 GHz~2.4835 GHz
5.725 GHz~5.875 GHz
90 dBμV/m at 3 meters
FM (video and audio)
PLL frequency synthesizer
1 V p-p/75 Ohm
1 V p-p/600 Ohm (STEREO)
RCA
RCA
Directional fl at antenna
940nm with ON/OFF keying
38 KHz
VHF low, VHF high, UHF
PAL B/G
100 Channels
9 V DC, 600mA
18×12×5 cm
500 g
2.400 GHz~2.4835 GHz
5.725 GHz~5.875 GHz
PLL frequency synthesizer
1 V p-p/75 Ohm
1 V p-p/600 Ohm (STEREO)
RCA
Directional fl at antenna
433.92 MHz
35 KHz~41 KHz
9 V DC, 400 mA
18×12×5 cm
410 g
