CONTENTS

1. Product characteristics

2. Description of the elements
3. Attaching and connecting the elements
4. Using the elements
5. Warnings to be respected
PRODUCT CHARACTERISTICS
This extremely easy to install colour video kit has excellent image quality and lets
you see and talk to your visitors.
.
Fitted with a button to open an automatic door opener or an electric lock (Maximum
12V 700mA).
.
Adapted to night vision with no need for outdoor lighting.
.
Simplified installation thanks to the built-in 2 wire technology.
THE STREET PANEL
. Operating temperature: -10 to +40°C.
. Night vision: 1.5 lux. Angle shot 62~90°.
. Dimensions: 157x 107 x 35.5 (mm).
. Surface mounting.
. Label holder.
THE INTERIOR MONITOR
. Operating temperature: 0 to +40°C.
. 7'' TFT LCD colour screen -17.5 cm.
. 0-15 metre cabling with cable supplied. 15 to 50 metres with 0.75 mm².
. Dimensions: 238 x 135 x 34 (mm).
. Surface mounting.
. Maximum duration of the exterior monitor:1 minute.
. Maximum communication time: 1.30 minute.
. Maximum lock opening time: 9 seconds.
. Ring tones: choice of 15.
ENGLISH
