8. Displaying Temperatures

1. Press to select the correct temperature scale.
C F K
• •
2. Hold or attach the thermocouple(s) to the measurement location. The
temperature reading appears in the primary display.
3. Press to toggle between showing the T1, T2 and
T T
1 2
T T
-
1 2
T1-T2 readings in the primary or secondary display.
Note:
The display shows "- - - -" when a thermocouple is not connected.
The display shows OL (Off Limit) when the temperature being measured
is outside the thermocouple's measurement range.

9. Freezing the readings

1. Press to freeze the readings on the display .
HOLD
The display shows HOLD.
2. Press to toggle showing the T1, T2 or T1-T2 readings
T T
1 2
T T
-
1 2
in the primary or secondary display.
3. Press again to turn off the HOLD function.
HOLD

10. Viewing the MAX, MIN, and AVG Readings

1. Press to step through the maximum (MAX), minimum (MIN), or
MAX
MIN
the average (AVG) readings. The elapsed time since entering
MAX, MIN mode, or the time at which the minimum or maximum
occurred appears on the display.
2. Press button for 3 seconds to exit MAX, MIN and AVG mode.
MAX
MIN

11. Replacing the Batteries

1. Turn off the thermometer.
2. Remove the screw and open the battery door.
3. Insert 3 × new LR03 batteries.
4. Close the battery door and tighten the screw.

12. Spare part

Designation
TDTC 1/X
SKF TKDT 10
Description
General toolcase without inlay, size X
