Connection and Settings When Using an FS-5U or Momentary-type Footswitch Pedal

TIP: TAP/REC/PLAY/DUB
For DELAY:
For LOOPER: LOOPER operation (p. 17)
Function
RING: DELAY/LOOPER MUTE
For DELAY:
For LOOPER: Mutes LOOPER
When
connecting
the FS-5U
CUBE-80X
Rear Panel
When
connecting
the FS-6
CUBE-80X
Rear Panel
14
Jack
Adjusts the delay time
Switches DELAY on and off
Red
(RING)
DELAY/LOOPER MUTE
PCS-31
Red White
(RING) (TIP)
DELAY/LOOPER MUTE TAP/REC/PLAY/DUB
REVERB EFX
SOLO SELECT
Jack
TIP: EFX
Switches EFX on and off
RING: REVERB
Switches REVERB on and off
PCS-31
Polarity switch
White
(TIP)
TAP/REC/PLAY/DUB
REVERB EFX
SOLO SELECT
Set the switches as shown bellow.
B
Jack
TIP: SELECT
Switches between the JC
CLEAN and LEAD channels
RING: SOLO
Calls up the SOLO function
A
