Start with the backpart of the seatunit. Take the shorter parts of the leg tubings and insert them
1
into the upper parts of the seat unit tubing.
Like you see in the picture. If you here a „click" they are fixed correctly.
After this take the front part. Fix the footrest over both short parts of the leg tubings. Again fix it
2
like before, one leg for each side- you need to hear a click to be sure it is right assembled.
Take the longer leg tubings and make each one fit to the smaller leg tubings. Again when you fix
3
the metal pin, into the tubings of the legs you can hear a click and know it is fixed well.
All four legs should be fixed properly. Please check it again and make sure everything is firmly
put together.
Take the bigger tray and slide it into the seat unit.
4
Take care the hole of the seat unit will be filled with the inner circle of the tray, like in the picture.
If it is right assembled you can here a „click" on both sides.
You can use the second clear tray on top of the bigger tray.
5
Use the support cushion for smaller childern in order to make them feel more comfy in the chair.
6
Warning: Prevent serious injury or death from falling or sliding out!
Attach the 5-point harness to the chair
7
Fill in the shoulderstraps first through the loops in the cushion after through the holes in the
backrest of the chair. Left and right side.
Fix them with the thicker sewed part through the hole. You can use the harness without cushion
as well. Assemble the same way, but without cushion.
Next step is to fix the waist straps. On the seat you can see 2 holes. One left one right please insert
8
the waist straps here.
Again fix it with the bigger sewed parts through the holes like shown in the picture.
Last step is to fix the crotch belt, same procedure. Fix the thicker part of the belt in the middle
9
hole of the seat (bottom). Take care it is fixed properly.
To adjust harness around your child, tighten shoulder and waist straps by sliding the adjusters
10-11
loosen or tighten. (Waist and crotchpad are adjustable through the harness buckle).
To unlock harness, push the button in the middle of the crotch buckle and pull harness straps of
the childs shoulders.
.
Important — Keep these instructions for future reference.
Warnings, safety instructions, maintenance, disposal and guarantee can be found in the warnings
booklet.
