Wall Switch RTS14
GB
Model
A
OPEN
(A1)
C
STOP
(C1)
CLOSE
B (B1)
RTS14E5002-01 OPEN/STOP/CLOSE
3 button operation
I O
A1
5 10
A2
15 20
C2
*)
RTS14E5002-02 -
ON/OFF
2 button operation
- Timer 5/10/15/20 min
1 button operation
*) to use preferably in connection with the
Junction Box Receiver RCJ01E5001-04
I O
1
ON B
(A1)
2
ON B
(A2)
3
ON B
(C2)
RTS14E5003-01
ON/OFF
2 button operation
A1
A2
C2
RTS14E5006-01 ON/OFF
1 button operation
Technical Data
Frequency: 868. 3 MHz
Modulation: FSK
Coding: Easywave
Power supply: 1x 3-V-battery, CR2032
Operating
temperature: -20 °C to +60 °C
Range: free-field: approx. 150 m
buildings: approx. 30 m
Degree of protection: IP30
Dimensions: 80 x 80 x 10 mm
Weight: approx. 47.0 g incl. battery
Package Content
Transmission module, 1x battery CR2032,
mounting frame, attachment set, op. instruc-
tion
Intended use
Only use the Radio Wall Switch RTS14 in dry
rooms to switch Easywave wireless controls.
The manufacturer shall not be liable for any
damage caused by improper or non-intended
A
OPEN
(A2) use.
STOP
(C2) C
Safety Advice
Before using the
CLOSE
B
(B2)
Switch
operating instructions!
Note also the operating instructions of the
radio control(s)!
Radio Wall Switch
The
operated within sight of the devices to be
controlled! Otherwise persons could be
placed in danger!
Have faulty
the manufacturer!
B2
Do not make any unauthorized alterations or
B2
modifications to the
D2
Function
The RTS14 is a wireless switch transmitter
for surface mounting in dry rooms.
The Easywave code is transmitted by
pressing the switch and the connected
Easywave wireless control switched.
Start-Up
1. Screw or stick
installation site with the help of the screws
and dowels or the adhesive pads.
Caution: Make sure that there is no inter-
B
OFF B
(B1)
ference with the wireless connection. Do
not mount the device in a distribution box,
OFF
B (B2) B
metal casings, in direct proximity to large
metal objects, on the floor or close to it.
OFF
B (D2)
2. Insert the enclosed battery.
Make sure the Polarity is correct!
3. First snap the transmission group in on
the top and then on the bottom of the
mounting frame. The arrow on the back
of the transmission module must point
upwards.
4. Register the transmission code with the
B1
wireless control.
operating instructions supplied with the
B2
radio controls.
D2
Transmission
module
Troubleshooting
If the wireless control does not react to the
wireless wall switch:
- Exchange the battery.
- Check that the wireless connection at the
installation site is not impaired between the
Radio Wall Switch
- Re-register the transmission code with the
wireless control.
- Other wireless devices using the same
frequency or working in direct proximity
may interfere with the device.
Radio Wall
, carefully read through the
should only be
Radio Wall Switch checked by
Radio Wall Switch !
the mounting frame to the
For this read the
Mounting
frame
and the wireless control.
Replacing the Battery
1. Carefully lever off the transmission group
out of the mounting frame on the bottom
edge.
2. Replace the battery. Only use batteries of
the type CR2032. Make sure the polari-
ty is correct!
3. Re-insert the transmission group into the
mounting frame.
Note: The transmitter's coding is preserved
even if there is no voltage supply. You do not
need to re-register the code with the wireless
control after a battery change.
Disposal
Waste electrical products and batteries not
be disposed of with household waste!
Dispose of the waste product via a
collection point for electronic scrap
or via your specialist dealer.
Dispose of used batteries in a
recycling bin for batteries or via the
specialist trade.
Put the packaging material into the
recycling bins for cardboard, paper
and plastics.
Warranty
Within the statutory warranty period we
undertake to rectify free of charge by repair or
replacement any product defects arising from
material or production faults.
Any unauthorized tampering with, or
modifications to, the product shall render this
warranty null and void.
Conformity
This product conforms to the
basic requirements of the R&TTE
Directive 1999/5/EC.
For use in: EU/CH/FL/IS/N
The Declaration of Conformity can be found
on the Internet at: www.eldat.de.
Customer Service
If, despite correct handling, faults or mal-
functions occur or if the product was da-
maged, please contact your retailer or the
manufacturer.
ELDAT GmbH
Im Gewerbepark 14
15711 Königs Wusterhausen
Germany
Phone: + 49 (0) 33 75 / 90 37-310
Fax: + 49 (0) 33 75 / 90 37-90
Internet: www.eldat.de
E-mail: info@eldat.de
UM79864B 0114 D/GB
Direction of
arrow must be
upward!
C R 2 0 3 2
+
