NOTE
Take care when using blower function. Ashes and other residue are blown away in an uncontrollable
way!

3. USAGE:

Vacuum cool ash and dry residue only
• Always make sure the filter is installed!
• When the container is full or it feels difficult to vacuum more dust, the filter needs to be taken out
and cleaned.
• While vacuum the fireplace ash, the ash temperature must be below 40°C. Do not vacuum the ashes
that fire is not extinguished! (Fig. 5)
G
TIP:
When suction power is reduced: carefully tap on the lid or carefully tap container to the floor to possi-
bly remove the blockade.

4. AFTER USAGE:

• Press the switch 12 to turn off vacuum cleaner.
• Pull out plug.
• Roll up the power cable.
• Disassemble the hose 7 from the appliance.
• Take the lid 3 from the appliance.
• Empty the container body 1 and wash it.
• Use rag to dry container body 1.
• Take out the filter B / C and (if applicable) the metal mesh cover D, and clean and wash it carefully
(picture 6), and dry it in air before installed on vacuum cleaner. Filter and metal mesh cover can be
removed using the 'turn anti clock wise and pull method'. For the metal mesh cover is might be nec-
essary to loosen the metal screws just a little bit.
• Reinstall B / C and D (if applicable) following the 'push and turn clock wise method'. Make sure that
the metal mesh filter is fixated by fixating the relative screws.
• Replace the lid 3 and fixate the locks 2

5. MAINTENANCE

The container body 1 and outer shell of lid 3 need to be cleaned frequently.
• Never use a detergent and/or cleaning agent as this might result in damages
• The dirty container should wash with the clear water only.
ASZ TYPE ONLY:
Make sure that water never comes in contact with the lid, as this can cause significant damage and or
risk with respect to the electrical parts!
• Wash the filter with the clear water only.
• If the appliance working unsatisfactory, it is usually resulted from the jam of hose 7 or conjunction of
pipes, filters or accessories. In that case, please clean the parts concerned.

6. CONSUMABLES AND SPARE PARTS:

• New filters can be obtained through your dealer. Check www.qlima.com for more information.
• Only use spare parts and/or consumables supplied by the manufacturer or its authorised service agent

7. TROUBLESHOOTING:

Review these tips first and you may not need to call for service.
