Faller 180730Soundmodul Bedienungsanleitung Seite 42

Generalviewofproduct
Port
16VAC
links
rechts
USB
Stick
LocoNet
Kontakt1-10
EN
GND(Masse)
LED
[LED]
Tab.1:Operatingelements
42
Description
Portforthesupplyvoltage
(16Valternatingvoltage)
Leftandrightloudspeakerports
Portforanactiveloudspeakersystem
PortfortheUSBmemorystick
PortforaLocoNetconnection,seealsochapter7.Inte-
restingfacts»Loco-Net«,page68
Portsforpushbuttons
Ground
Description
IndicatorLED(flasheswhenconnectioniscorrect)
