FOREWORD:
• The soft one-touch electroluminescent keypad has 12 keys; (see fig. 1) an acoustic signal
can be heard each time a key is pressed.
- 10 numerical keys from 0 to 9 and 26 letters.
- There are 1,111,111,110,000 possible combinations.
- The ENTER key confirms the code that has been entered.
- The CLEAR key deletes all previously entered letters and numbers.
• All safes are supplied with the service code "555555".

INSTALLATION:

• Doors on wall safes must be left open for 2/4 days after installation.
• After the safe has been installed insert four new 1.5 V alkaline batteries in the battery
compartment on the inside of the door (fig. 2), (use only alkaline batteries).
• In order to enter your personal safe combination code read the following "INSTRUCTIONS
FOR USE" carefully.
INSTRUCTIONS FOR USE:
1
OPERATION
STORING A PERSONAL CODE
THIS OPERATION MUST BE PERFORMED WITH THE DOOR OPEN
• Get a pencil (which will be used to press the zero reset button).
a) Turn the knob counter-clockwise to shoot the bolts.
b) Type "555555" and press
The green led will light for 10 sec.
c) Before the 10 seconds have elapsed press the reset button on the inside of the door using
the end of a pencil (see fig.3).
An acoustic signal will be heard and the green led will illuminate for 20 seconds
d) Before the 20 seconds have elapsed type your personal code (min. 4 digits, max. 12) and
press .
The red led will illuminate for 20 seconds
e) Before the 20 seconds have elapsed enter your personal code again and press the ENTER
key .
If the personal code has been correctly stored the two leds will switch off
2
OPERATION
PERSONAL CODE VERIFICATION
THIS OPERATION MUST BE PERFORMED WITH THE DOOR OPEN
a) Type your personal code and press
The green led will illuminate for 10 seconds
knob.
b) Draw back the bolts with the knob.
c) Repeat the aforementioned steps several times to check locking and unlocking operations.
3
OPERATION
LOCKING THE DOOR:
a) Remove the nylon safety plug that blocks one of the holes on the striker.
b) Close the door and turn the knob counter-clockwise to shoot the bolts.
INSTRUCTIONS FOR SAFE WITH ELECTRONIC
COMBINATION LOCK
.
.
.
: effective time for drawing back bolts with
.
.
.
.
ZERO RESET
BUTTON
EXTERNAL POWER INPUT
LEDS
BATTERIES
Fig. 3
PENCIL
®
GB
Fig. 1
Fig. 2
