Installation Instructions - Frame Fx - Novoferm NovoDock L100 Montageanleitung

8.1
L1
Steel 55 mm
Instruction: Complete FX pre-fame is third-party supply.
General instruction: The image may differ at detail level.
This installation manual must be given to the customer and kept safely during the entire period of use!
L2 L3 L4
10 mm 20 mm 105 mm

8. Installation instructions - frame FX

a4
a4
L5
6
328 mm
50 x 15 - 70
7
75 x 50 x 7 - 50
EN
11
