Basic Use
4
Before use, move all sliders on the sides completely back into
their starting positions (1).
Press the unlocking button (2) and move the slider you have
selected forward until it clicks into place (3).
Connect the device plug receptacle of the electrical circuit to
the adapter (4).
Connect the adapter to the mains (5).
2
5
3
1
(Shown: World Adapter Pro+)
Setting up the plug for
Switzerland / Italy
Switzerland Italy
Push out the Switzerland / Italy plug until it locks into place (as
described before) (1). Changing from the Italian to the Swiss
plug (all three pins must be aligned in a row): Push middle pin
to the left with slight force until you hear a distinct "click" (2).
Then push the pin on the top to the right (3).
The adapter is not ready for use until all three pins are in the
vertical position. To change to the setting for Italy, simply
reverse the procedure (4).
click!
1
3
2
4
5
