StarTech.com HSB2535SATBK Bedienungsanleitung

5.25in dual 2.5/3.5in hdd/ssd sas sata trayless mobile rack
Vorschau ausblenden
Inhaltsverzeichnis

Werbung

Quicklinks

Diese Anleitung herunterladen
5.25in Dual 2.5/3.5in HDD/SSD SAS SATA
Trayless Mobile Rack
HSB2535SATBK
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 09/20/2013
*actual product may vary from photos

Werbung

Inhaltsverzeichnis
loading

Verwandte Anleitungen für StarTech.com HSB2535SATBK

Inhaltszusammenfassung für StarTech.com HSB2535SATBK

  • Seite 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 09/20/2013...
  • Seite 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...

  • Seite 3: Inhaltsverzeichnis

    Table of Contents Product Diagram ..................1 Front View ..............................1 Rear View ..............................1 Introduction ....................2 Packaging Contents ..........................2 System Requirements ..........................2 Hardware Installation ................3 2.5/3.5in Hard Drive Installation ......................4 2.5/3.5in Hard Drive Removal ....................... 5 How to Use ....................6 Connecting the Hard Drive ........................

  • Seite 4: Product Diagram

    Product Diagram Front View 1. 2.5” Drive bay 2. 2.5” Drive bay key hole 3. 3.5” Drive bay 4. 3.5” Drive bay key hole 5. 2.5/3.5in LED indicators Rear View 1. 2.5” Drive SATA port 2. 3.5” Drive SATA/SAS Port 3.

  • Seite 5: Introduction

    Introduction Packaging Contents • 1 x 2.5/3.5in SATA HDD Backplane • 2 x 18” SATA Cable • 1 x Molex LP4 to SATA Power Adapter Cable • 2 x Bay Key • 1 x Installation Screw kit • 1 x Instruction Manual System Requirements •...

  • Seite 6: Hardware Installation

    6. Connect a Molex LP4 Power header from your power supply to the “LP4 Power Connector” on the back of the HSB2535SATBK. If you do not have an LP4 connector available, use the included “Molex LP4 to SATA Power Adapter Cable” with an available SATA Power Header from your power supply.

  • Seite 7: 3.5In Hard Drive Installation

    2.5/3.5in Hard Drive Installation 1. Insert either of the included bay keys into the “2.5in/3.5in Drive bay key holes depending on which type of drive you intend to install. And Turn the key clockwise into the unlock position. 2. Pull the drive door handle to open the drive bay. 3.

  • Seite 8: 3.5In Hard Drive Removal

    2.5/3.5in Hard Drive Removal 1. Insert either of the included bay keys into the “2.5in/3.5in Drive bay key holes depending on which type of drive you intend to install. And Turn the key clockwise into the unlock position. 2. Pull the drive door handle to open the drive bay. 3.

  • Seite 9: How To Use

    Refer to Initializing the Hard Drive LED Indicator The HSB2535SATBK offers 2.5/3.5in LED indicators, to enable you to monitor drive activity. The LED will flash while the hard drive is being accessed. Do not remove the enclosure from the host computer while the LED is flashing, as it could damage the drive or the enclosure, resulting in data loss.
  • Seite 10 2. A dialog window should automatically appear, asking you to initialize the drive. Depending on the version of Windows, it will give you the option of either creating an “MBR” or “GPT” disk. GPT (GUID partition) is required for drives larger than 2TB but is not compatible with some older operating systems, while MBR is supported by newer and older operating systems.

  • Seite 11: Technical Support
