AEG X89264MI10 Gebrauchsanleitung Seite 4

www.aeg.com
4
4. CONTROLS
Button Function
A
B
C
D
E
F
5. LIGHTING
Warning: This appliance is fitted with a
white LED lamp classed as 1M according
to EN 60825-1: 1994 + A1:2002 + A2:2001
standards; maximum optical power emitted
@439nm: 7µW. Do not look directly at the light
through optical devices (binoculars, magnifying
glasses...).
• For replacement contact technical support.
("To purchase contact technical support").
A B
Turns the suction motor on and off at speed one.
Decreases the working speed.
Increases the working speed.
Activates intensive speed from any other speed, including
motor off. This speed is set to operate for 5 minutes, after
which the system returns to the speed that was set before.
Suitable to deal with maximum levels of cooking fumes.
When the filters alarm is triggered, the alarm can be reset
by pressing and holding this button for approximately 3
seconds. These indications are only visible when the motor
is turned off.
Delay function
Activates automatic switch-off with a 20' delay. Suitable to
complete elimination of residual odours. Can be activated
from any position, and is disabled by pressing the button or
turning the motor off.
Press and hold the button for approximately 5 seconds,
with all the loads turned off (Motor and Lights), to turn the
Activated Charcoal Filter alarm On and Off.
Turns the lighting system on and off at maximum intensity.
C D E
Display
Displays the set speed
Displays the set speed
Displays the set speed
Displays HI and the time remaining
once every second.
F indicates the need to wash the
metal grease filters. The alarm is
triggered after the Hood has been in
operation for 100 working hours.
C indicates the need to change the
activated charcoal filters, and also to
wash the metal grease filters. The
alarm is triggered after the Hood has
been in operation for 200 working
hours.
Displays the operating speed and
the dot at the bottom right flashes
alternately with the remaining time.
- C flashes twice - A.C. Filter alarm
Activated.
- C flashes once - A.C. Filter alarm
Deactivated
F
